Review Article - (2016) Volume 7, Issue 7
Eastern blotting was developed for small molecule compounds which have no affinity of conjugation to membrane instead of western blotting. Crude extracts of medicinal plants were developed by TLC plate followed to be blotted to polyvinylidene fluoride or polyether sulfone membrane by heating. Components on membrane were conjugated with carrier protein resulting in fixing to membrane. Staining was followed to western blotting system using monoclonal antibody (MAb). Four types of natural products, solasodine glycosides, aristrochic acid, glycyrrhizin-liquiritin and ginsenosides were discussed in this review. 1) Solasodine glycosides are selected as an example of staining for almost all solasodine glycosides using the anti-solamargine MAb having wide cross-reactivity. 2) Aristrochic acids possess no capacity of conjugation with membrane and their aqueous solubility is quite poor. To improving them, aristrochic acids should be synthesized for conjugation with carrier protein in order to combine to membrane. 3) Two different types of marker components in licorice, triterpene glycoside; glycyrrhizin and flavonoid glycoside; liquiritin can be detected by double eastern blotting. 4) Ginsenosides are also detected by double eastern blotting and this system might be possible to clear the distribution of ginsenosides in tissue for understanding of pharmacological activity.
Keywords: Eastern blotting; Monoclonal antibody; Solasodine glycoside; Aristolochic acid; Glycyrrhizin; Liquiritin; Ginsenoside
Recently immunoassay systems using monoclonal antibody (MAb) against drugs and bioactive compounds having small molecular weight have become an important tool in wide field. We prepared many MAbs against natural products like forskolin [1], solamargine [2], crocin [3], marihuana compound [4], opium alkaloids [5], ginsenosides [6,7], berberine [8], sennosides [9,10], paeoniflorin [11,12], glycyrrhizin (GC) [13,14], saikosaponin [15-17], ginkgolic acid [18], aconitine alkaloid [19] and baicalin [20]. More recently MAbs against capsaicinoids [21], artemisinin [22,23], luteoloside [24], daidzin [25] and puerarin [26] have been prepared and developed individual competitive enzyme-linked immunosorbent assay (ELISA) as a high sensitive, specific, and simple methodology resulting in screening of medicinal plants targeting bioactive component [27], pharmacokinetics for capsaicinoids [21] artemisinin [28], and ginsenoside Rb1 and Rg1 [29].
The one-step purification of the target component which is an antigen molecule like forskolin [30], ginsenoside Rb1 [31], solasodine glycosides [32] and GC [33] and naringin [34] by immunoaffinity column conjugated with MAb has been succeeded. In the case of GL the extract eliminated GL was tested the biological activity and confirmed that the extract seemed to be a knockout extract [35-37].
As an immunostaining technique to detect higher molecular compounds like peptides and proteins using MAb western blotting is used widely. However, since small molecular compounds are ruled out from western blotting, a new staining system for small molecule compounds might be required. Therefore we separated the function of western blotting into 3 steps; separation of compounds by thin-layer chromatography (TLC), blotting to polyvinylidene fluoride (PVDF) or polyether sulfone (PES) membrane and finally staining by MAb. Since blotted compounds on PVDF or PES membrane are easily washed out by washing, the compounds on membrane were combined with carrier protein resulting in fixing on membrane and then staining. For the conjugation of antigen molecule to carrier protein two methods were used; one is oxidative cleavage of sugar moiety releasing the aldehyde group which can be conjugated to carrier protein, and the other is expanding of function by appropriate linker resulting in an antigen molecule and carrier protein conjugate on the membrane. This methodology has been applied for several natural products like solasodine glycosides in Solanum spp. [38], saikosaponin in Bupleurum spp. [39], sennosides in Rheum spp. [40], ginsenosides in Panax spp. [41,42], GC [14] and liquiritin (Liq) [43] and so on. Therefore, we will discuss four types of natural products, solasodine glycosides, aristrochic acid, GC and ginsenosides in this review. Solasodine glycosides are selected as an example of staining for almost all solasodine glycosides using the MAb having wide cross-reactivity. Aristrochic acid should be synthesized for conjugation with carrier protein in order to combine to membrane compared to the other groups. In the case of licorice we selected two different types of marker components, triterpene glycoside; GC and flavonoid glycoside; Liq for fingerprinting by double eastern blotting. Final ginsenosides are the delegation of double eastern blotting for recognizing of pharmacological activity.
The natural resources of adrenocortical and sex hormones, which are mainly obtained from diosgenin purified from Dioscorea saponin, are decreasing (Figure 1). The most important feature of solasodine is that it can be converted to dehydropregnenolone. Solasodine is found with a series of sugar residues attached to the oxygen at the C-3 position. The most common forms are the triglycosides, solamargine being predominant [44]. Therefore, the steroidal alkaloid glycosides of the solasodine type like solamargine have become important as a starting material for the production of steroidal hormones in the market. In order to analyze the concentration of solasodine glycosides in Solanum spp. we prepared MAb against solamargine having wide cross reactivity for almost all solasodine glycosides [2] which can be used as resources for steroidal hormones. Figure 2 indicates the crossreactivities of MAb against solamargine. Other steroidal compounds, however did not cross-react with anti-solamargine MAb. Judging from above findings, it is clear that an aglycone and part of the glucose are immunogenetic resulted in that almost all solasodine type glycosides can be detected by anti-solamargine MAb.
Solasodine glycosides were applied to two TLC plate and developed by developing solvent system [38]. One plate was sprayed and colored with H2SO4. The other plate was blotted to a PVDF membrane by heating. The PVDF membrane was treated with sodium periodate releasing aldehyde group in a molecule followed to add BSA solution. Conjugate reaction occurred between aldehyde and BSA to give a shif base which combines to PVDF membrane. Figure 3 shows the pathway of solasodine glycoside-BSA conjugate on PVDF membrane.
In order to confirm the preparation of solamargine-BSA conjugate on the PVDF membrane, the band corresponding to the solamargine- BSA conjugate was assessed by MALDI mass spectrometry. A broad peak of solamargine-BSA conjugate appeared at around m/z 69043 in MALDI mass spectrometry indicating clear conjugation between solamargine and BSA occurred because BSA molecule is 66464. Therefore, it becomes clearly that the sugar moiety which was conjugated with BSA is necessary in this staining system. Then after anti-solamargine MAb was added to the membrane which was treated with peroxidase labeled secondary MAb and a substrate. Figure 4 indicated the fingerprinting by eastern blotting for several solasodine glycosides using anti-solamargine MAb. All of solasodine glycosides can be stained.
Figure 4: Fingerprinting by eastern blotting for several solasodine glycosides using anti-solamargine MAb. Lines 1 to 11 are solamargine, solasonine, khasianine, 3-O-β-D-glucopyranosyl solasodine, O-α-L-rhamnosyl-(1→2)-3-O-β-D-glucopyranosylsolasodine, 3-O-β-D-galacopyranosyl-solasodine, O-β-Dglucopyranosyl-(1→3)-3-O-β-D-galacopyranosyl-solasodine, solaverine I, solaverine II, 12-hydroxysolamargine and 12-
hydroxysolasonine, respectively. Two μg of samples were applied for TLC, respectively.
Figure 5A showed the fingerprinting of Solanum spp. by eastern blotting using anti-solamargine MAb. It clearly showed that solamargine and solasonine are major solasodine glycosides in Solanum spp. and solasodine mono-glycoside can be detected in only S. khasianum. On the other hand the fingerprinting by H2SO4 (Figure 5B) indicated complicated pattern, because that H2SO4 detected the other type of glycosides like triterpene and/or steroidal components. The present methods are useful to determine solasodine-type glycoalkaloids. The combination assay method of their ELISA [2] and eastern blotting can be routinely used to survey natural resources for solasodine glycosides as a simple and rapid analysis. As we previously reported when analysis of lower concentrations of solasodine
Figure 5: The eastern blotting (A) and TLC stained with H2SO4 (B) of Solanum spp. Lines 1 to 15 are solasonine, solamargine, S. khasianum, S. lyratum, S. spirale, S. melongena, S. stramonifolium, S. verbascifolium, S. indicum, S. aculeatissimum, S. trilobatum, P. minima, S. wrightii, S. torvum and S. nigrum, respectively.
glycosides is required an immunoaffinity column conjugated with antisolamargine MAb is available. The elution from the column concentrates the solasodine glycosides. Therefore, an immunoaffinity column, ELISA and eastern blotting represent strong methodology for detection, quantitative analysis, and single step isolation for total solasodine glycosides [33].
Aristolochia species
Aristolochic acids (AAs), naturally occurring nephrotoxicants and human carcinogens, are associated with the development of a rapidly progressive interstitial nephritis called aristolochic acid nephropathy (AAN) [45], and may also be a cause for the Balkan Endemic Nephropathy (BEN) [46](Figure 6). AAs are a mixture of structurally related nitrophenanthrene carboxylic acids [47]. Among them, aristolochic acid I (AA-I, Figure 7) and its 8-demethoxylated form, aristolochic acid II (AA-II, Figure 7), are considered to be of particular significance [48,49].
It has been revealed that both AA-I and AA-II possess nephrotoxicity and/or genotoxicity [50-52]. AA-I and AA-II were found in the herbal medicines of Aristolochiaceae plants including Aristolochia and Asarum species [45,47,53], which have been prescribed for the traditional Chinese medicines (TCM) for centuries. Since the first evidence that the interstitial renal fibrosis rapidly progressed to end-stage of renal disease caused by the misuse of a slimming regimen containing AAs was reported in Belgium during 1990s [54], many countries started to regulate the herbs and supplements derived from Aristolochia and Asarum species. Although several species are listed in Chinese Pharmacopoeia in China, the number has been decreasing. Asiasarum sieboldii F. Maekawa and Asiasarum heterotropoides F. Maekawa var. mandshuricum F. Maekawa are still listed in the Japanese Pharmacopoeia (2011 edition) and severe quality control is described such as no detection of AAs by HPLC. In order to minimize the potential health risk aroused by AAs, a simple and sensitive method allowing visual detection might be highly required for the screening of a large number of herbal samples containing AAs. Detection methodology of AA-I and AA-II has been extensively reported, mainly focusing on the development of HPLC methods [55-57]. Compared to HPLC analysis, immunoassay systems have been proving simpler, more environmental-friendly and more rapid. For those benefits, ELISA using anti-AAs polyclonal antibody (PAb) [58] and anti-AA-I and AA-IVa MAb [59] have been reported previously. We also prepared anti-AA-II MAb [60] and anti-AA-I and - II MAbs [61], and then investigated the localization of aristolochic acids in mice kidney [62] resulting in finding of α-actinin-4 as a possible target protein for aristolochic acid I in human kidney cell [63]. However, no immunostaining technique utilizing anti-AA MAb or anti-AA PAb has succeeded yet, due to the fact that AAs possess no capacity of conjugation with membrane and their aqueous solubility is quite poor. AAs, as the small molecules, will be easily washed out by buffer solutions during immunostaining process without fixation as previously described in solasodine glycosides which can be cleavage on sugar moiety to give aldehyde group in a molecule. Therefore, special fixing step was necessary so that AA could be blotted onto a membrane from the developed TLC plate. To facilitate the fixation to membrane, a modified carboxyl activation method was employed. 1-Ethyl-3-(3’- dimethylaminopropyl) carbodiimide hydrochoride (EDC) method was commonly used to link the carboxyl groups of small molecular compounds to the amine groups of protein. We have been successfully prepared for immunization for various kinds of conjugates, succinate method like forskolin [64] and crocin [3], and conjugate with BSA through alanine in marihuana compound [65]. Considering the fact that the addition of N-hydroxysuccinimide (NHS) could improve the stability of the intermediate and enhance the yield [66], the routine procedure was thereby improved by the addition of NHS together with EDC. After adding NHS, the carboxyl group of AA-I could be activated to form a semi-stable NHS ester. This intermediate can be coupled with the amine groups of carrier protein like BSA, resulting in the formation of AA-I-BSA conjugate which can be fixed on the PES membrane.
Figure 8 indicated the pathway of AA-1-BSA conjugate preparation which created a function of conjugating with PES membrane. The membrane was stained by the same way as previous solasodine glycosides using anti-AA-I MAb, secondary MAb and finally substrate, 4-chloro-1-naphthol. The other TLC plate developed was detected by UV light at 254 nm.
Figure 9 indicated the fingerprinting profiles of plant extracts by eastern blotting and TLC plate detected by UV light at 254 nm. Although many spots including AAs and ALs were detected in Aristolochia species at 254 nm (Figure 9B), only AA-I and AA-II were detected by eastern blotting (Figure 9A). As shown in Figure 9A the stem of A. manshuriensis (Lane 1), the root of A. cinnabarina (Lane 3) and the root of A. contorta (Lane 4) were stained clearly on the membrane, whereas the root of A. fangchi (Lane 2), the root of A. debilis (Lane 5), the whole plant of A. mollissima (Lane 6) and the fruit of A. contorta (Lane 8) were stained weakly. On the other hand, the other species and the root parts could not be stained. It was suggested that the established eastern blotting system based on anti-AA-I and AA-II MAb was considerably more specific than TLC method.
Licorice
Glycyrrhiza species (Leguminosae) is perennial plants growing up to 1.5 m high. These plants are generally distributed in drylands between Western Europe to Russia and particularly abundant in China and Mongolia. Licorice, the root of Glycyrrhiza species, is listed in Material Medica and Shennong Ben Cao Jing as an important and safe medicine, and therefore it is well-known that one of the most important herb medicine used in TCM and prescribed with other herb medicine in 70% of prescription for a tussive, expectorant and corrigent, treatment of nervous, alimentary, respiratory, endocrine, and cardiovascular system diseases and so on [67]. These pharmaceutical properties are mainly due to GC which has protein inhibitory activity, anti-ulcer and anti-viral activities [68-70] and is now used for protection of the lever and as an anti-allergic during this fifty years in Japan [71]. Major species, G. uralensis Fisch (Figure 10) and G. glabra Linne are listed in the Japanese pharmacopoeia. Five hundred or more components have been identified in licorice, including GC which is controlled at a concentration of more than 2.5% and a flavonoid, Liq has a quantitative limitation in Japanese Pharmacopoeia too (Figure 11). Flavonoids have also wide pharmacologically active spectra like anti-hepatotoxic, antiinflammatory, anti-ulcer, anti-allergenic, and anti-viral activities as well as cardioprotective activities [72-76]. Licorice is also widely used as a sweetener in the production of confectioneries, soy sauce and is therefore in high demand worldwide. An anti-GC MAb was prepared in our laboratory [14] and we previously reported on the synergistic effects of GC and other constituents [37], the interfacial behavior of GC [77], and the identification of Glycyrrhiza species with higher GC content [27]. More recently we found that two flavonoids, isoliquiritigenin and formononetin promote in vitro fertilization [78].
Aristrochia species
GC and Liq are two major components in licorice that have wellknown pharmacological activities as documented above. Quality control of licorice root is needed to assure uniformity in the concentrations of these compounds, which can differ according to licorice species, growth place, and harvest season, and so on. We also previously prepared MAbs against Liq [43] for quality control of licorice in order to make evident the resource of licorice for further researches.
We discussed eastern blotting for solasodine glycoside using antisolamargine MAb having wide cross-reactivity previously. On the other hand we prepared a high specific anti-GC MAb indicating that the cross-reactivity of aglycone of GC, glycyrrhetic acid and glycyrrhetic acid-mono-glucuronide were 2 and 4%, respectively [14]. MAb against Liq is almost same with that of GC although an aglycone of Liq has lower cross-reactivity [14]. Therefore, double eastern blotting of GC and Liq was performed on the basis of the previously described methodology. Moreover, although a double eastern blotting had been developed for detecting structurally related compounds such as ginsenosides (dammarane-type triterpenoid saponin) [41] and sennosides (anthraquinone glycoside) [40], detecting two compounds that differ chemically such as GC (triterpenoid saponin) and Liq (flavonoid glycoside) has not been achieved yet.
GC, glycyrrhetinic acid, Liq, liquiritigenin and a sample extract solution were applied to the TLC plate and developed with butanolwater- acetic acid solvent system After blotting from the TLC plate to the PES membrane, the blotted membrane was treated with a sodium periodate solution and then treated with BSA solution. The membrane was treated with anti-GC MAb, peroxidase-labeled secondary antibody, and 3-amino-9-ethylcarbazole. For successive staining by anti-Liq MAb, the PES membrane was treated in the same manner as the anti-GC MAb except that it was exposed to 4-chloro-1-naphthol.
GC and Liq on the membrane can be detected by labeling with anti- GC and anti-Liq MAbs (Figures 12B and 12C). However, two aglycones cannot be stained by eastern blotting (Figure 12B) because unlike TLC (Figure 12A), there are no sugar moieties that can be conjugated to the membrane as previously conformed in solasodine glycoside.
Samples 1 ~ 4 are GC, glycyrrhethic acid, Liq and liquiritigenin in (A) and (B), respectively. Samples 1 ~ 8 in (C) are GL and Liq standard solution as 20, 10, 5, 2.5, 1.25, 0.63, 0.31 and 0.16 μg, respectively.
Because 4-chloro-1-naphthol and 3-amino-9-ethylcarbazole were compatible with a peroxidase-labeled secondary antibody, double eastern blotting was employed for these substrates. 4-Chloro-1- naphthol was found to be unsuitable for GC analysis in licorice and licorice products because the bands were unclear. Instead, 3-amino-9- ethylcarbazole was selected for GC staining, which give a reddish color. Thereby, Liq gave a purple color when stained with 4chloro-1- naphthol. These results demonstrate that 3-amino-9ethylcarbazole and 4-chloro-1-naphthol were suitable for the detection of GC and Liq, respectively. In evaluating the sensitivity of double eastern blotting, various concentrations of GC and Liq were detected using anti-GC and anti-Liq MAbs. The colored GC and Liq spots appeared by double eastern blotting at a minimum of 0.63 μg. Although GC, Liq, and their aglycones, glycyrrhetinic acid and liquiritigenin, can be detected by sulfuric acid staining, double eastern blotting using anti-GC and anti- Liq MAbs can only detect GL and Liq. The advantage of using double eastern blotting compared to TLC analysis, is that it is possible to identify GC and Liq in impure or crude sample extracts without any standard compounds and their retention factors. Another advantage of this immunostaining system is that it enables identification of licorice from different plant species based on a one-step analysis, although licorice contains nearly 500 constituents, which normally would result in complicated component patterns, making it nearly impossible to identify licorice without suitable pretreatment using TLC and HPLC. Moreover, although several compounds and other crude drugs are present in Kampo medicine, the concentrations of GC and Liq in various Kampo medicines were in good agreement with the color depth and band size of the stains by double eastern blotting.
Ginseng
Genus Panax mainly includes 4 species, P. ginseng, P. japonicus , P. quinquefolium and P. notoginseng . Among them, P. ginseng was listed as the upper class medicine in Shén nóng ben cao jing nearly 2 thousand years ago and has the centuries-old history. It has been used in forms of extract, powder, tea, tablet, capsule, etc., for their ability to enhance physical performance and for their adaptogenic effects, which are believed to increase the body’s ability to fight stress, increase resistance to disease by strengthening normal body function, and reduce aging process. Phytochemical of ginseng has been studied extensively and, to date, more than 100 dammarane-type triterpene oligoglycosides, generally named as ginsenosides such as ginsenosides Rb1, Rb2, Rg1, Rd, Re, have been identified [79,80] (Figure 13).
Regarding eastern blotting we already discussed three types of compounds like solasodine glycosydes in Solanum spp., aristolochic acids in Aristolochia species and GL and Liq in Glycyrrhiza species. Solasodine glycosides are an example of determination for all solasodine glycosides using MAb having wide cross-reactivities. Next we discussed how to conjugate to membrane for compounds having no sugar moiety in a molecule using aristolochic acids. In licorice two types of compound like triterpene glycoside and flavonoid could be detected by double eastern blotting. In this section double eastern blotting system can be used for staining for ginseng saponins.
However, since 100 ginsenosides have been isolated and elucidated structures, the identification of individual ginsenosides is not easy. However, since two MAbs against ginsenoside Rb1 and ginsenoside Rg1 can recognize almost all ginsenosides although two MAbs are specific [81,82].
There are two types of ginsenosides related to aglycone, protopanaxdiol and protopanaxtriol. Therefore we prepared two MAb against ginsenoside Rb1 and Rg1 [6,7]. Figure 14 indicated two types of ginsenoside, ginsenoside Rb1 and ginsenoside Rg1. Difference between two ginsenosides is the position of glucose conjugation to aglycone. In the case of ginsenoside Rb1 no glucose conjugated at C6 positon. On the other hand ginsenoside Rg1 has one glucose conjugated at C6 hydroxyl group.
Figure 15 showed the double eastern blotting (B) and H2SO4 staining (A) of various Panax species. Pinkish spots indicated ginsenoside Rg1 and Re possessing protopanaxatriol as an aglycone. On the other hand, blue color showed ginsenoside Rb1 and Rc and so on which have protopanaxadiol in a molecule. It is suggested that the specific reactivity of the sugar moiety in the ginsenoside molecule against MAb may be fortunately modified by sodium periodide treatment of ginsenoside on the membrane resulting in wide crossreactivity although the protopanaxadiol and protopanaxatriol groups are still recognized each other. If anti-ginsenoside Rb1 MAb will be used, all ginsenosides having protopanaxadiol as an aglycone can be stained. Anti-ginsenoside Rg1 can stain almost all ginsenoside having protopanaxatriol as an aglycone. This double eastern blotting has the other function because ginsenosides of protopanaxadiol group have the suppressive activity for central nervous system [83]. On the other hand ginsenosides having protopanaxatriol indicate excite activity for central nervous system [84]. Therefore, Figure 15 indicates that blush color ginsenosides have the suppressive activity and pinkish ginsenosides have exciting activity. Therefore, it becomes evident that we will be able to evaluate the pharmacological activity against ginsenosides by double staining using anti-ginsenoside Rb1 and Rg1 MAb.
Figure 15: H2SO4 staining (A) and double eastern blotting (B) of various Panax spp. II, III, IV, V and VI indicated white ginseng, red ginseng, fibrous ginseng (Panax ginseng), Panax notoginseng, Panax quinquefolius and Panax japonicus, respectively. Upper purple color spots and lower blue color spots were stained by anti- G-Rg1 and anti-G-Rb1 monoclonal antibodies, respectively.
Since we have succeeded to determine the distribution of ginsenoside Rb1 in ginseng tissues [84,85], our previous result of pharmacokinetics for ginsenosides Rb1 and Rg1 [29] makes it possible clear the distribution of ginsenosides Rb1 and Rg1 in tissues. Furthermore, it might be possible to confirm the distribution of ginsenoside Rb1 and Rg1 in a brain by double eastern blotting using anti-ginsenosides Rb1 and Rg1 MAbs in order to make evident the relation between the structure of ginsenoside and pharmacological activity in central nervous system as suggested previously.
In this review, we described the eastern blotting for quality control of natural products. Eastern blotting is an on-membrane immunestaining and quantitative analysis system for natural products. We introduced several examples such as solasodine glycosides, aristrochic acid, glycyrrhizin, liquiritin, and ginsenosides. The MAbs which we prepared have different cross-reactivities against each target compounds. By using the useful property of these MAbs, eastern blotting is specific and sensitive compared with TLC to determine the target compounds in crude extracts of medicinal plants. Double eastern blotting made possible to detect two different compounds in same membrane using different substrates for secondary antibodies. Moreover, the histochemical study of plant using eastern blotting is possible to investigate the distribution of target compounds in the sliced plant. In addition, eastern blotting also made possible the detection of target compounds in biological sample like tissue. These applications using eastern blotting may open the possibility to develop the quality control of natural products, and to apply the analysis of plant morphology and biological study related with natural products.
