Research Article - (2017) Volume 8, Issue 12

In vitro and In vivo Antifungal Activity of Culture Filtrates and Organic Extracts of Penicillium sp. and Gliocladium spp. against Botrytis cinerea

Hassine M1*, Jabnoun-Khiareddine H2, Aydi Ben Abdallah R2 and Daami-Remadi M2
1National Institute of Agriculture of Tunis, University of Carthage, Tunisia
2Integrated Horticultural Production in the Tunisian Centre-East, Regional Center of Research on Horticulture and Organic Agriculture, University of Sousse, Chott-Mariem, Tunisia
*Corresponding Author: Hassine M, National Institute of Agriculture of Tunis, University of Carthage, Tunisia, Tel: +21673327543 Email:

Abstract

Eight isolates of Penicillium sp. and two isolates of Gliocladium spp. were tested in vitro and in vivo for their inhibitory effects against Botrytis cinerea, causal agent of tomato fruit grey mold. The biocontrol essays conducted in vitro revealed that the culture filtrates of the isolates tested have significantly reduced the mycelial growth of the pathogen. The filtrates of the isolate CH6 of Penicillium sp. applied at different concentrations (10, 15 and 20% v/v), was most effective in reducing B. cinerea colony diameter. The ethyl acetate and chloroform extracts of the isolates CH6 of Penicillium sp., Gc1 of G. catenulatum and Gv1 of G. virens have shown an inhibitory effect of the pathogen radial growth, at the concentrations used (1, 2.5 and 5% v/v). In addition to the reduction of the mycelial growth of B. cinerea, these antagonistic agents have induced important morphological alterations to the mycelium of the pathogen. These antagonists were applied to tomato fruits 2 hours before their inoculation with the pathogen. Tested as culture filtrates, the most effective isolates CH11 and MC1 of Penicillium sp. and Gv1 of G. virens had significantly reduced the severity of the disease compared to the inoculated and untreated control fruits. Similar effects were recorded using the ethyl acetate and chloroform extracts of the tested antagonists; those of CH6 and CH5 of Penicillium sp. and Gc1 of G. catenulatum were found to be the most effective in reducing severity grey mold. Thus, this study showed the presence of bioactive molecules in the culture filtrates of the antagonistic agents used and also allowed the selection of effective isolates for grey mold disease control.

Keywords: Biological control; Culture filtrates; Gliocladium spp.; Organic extracts; Penicillium sp.; Tomato rot

Introduction

Tomato (Solanum lycopersicum L.) is the second most consumed and most economically important vegetable crop worldwide after potato and constitutes a major agricultural industry [1]. Its adaptability to different climatic conditions [2] as well as different latitudes makes it the most cultivated crop on nearly a third acreage of global vegetable crop. Tomatoes are consumed either fresh or as economically important processed products [3] and have significant nutritional value; they are a good source of vitamin C, vitamin A and antioxidants.

In Tunisian agriculture, tomato crop occupied a strategic position. It is cultivable over 24,231 ha with a production of more than 1,040,100 T/year [4]. However, this crop is subjected to several viral, bacterial, and fungal attacks, especially in pre-and post-harvest stages [5]. Among common tomato fruit rot diseases, grey mold caused by Botrytis cinerea Pers. is of particular concern [6,7]. This pathogen has an exceptionally wide host range and is widespread in almost all tomato production areas and is responsible for considerable economic losses of up to 50% in some African countries [5]. B. cinerea can infect the plants either by direct penetration or through wounds caused by cultivation practices and during transport, storage, and marketing [8]. High humidity, free moisture on the plant surface, and low temperatures are conducive to fungal development [9].

Management of B. cinerea has heavily relied on the use of chemical fungicides which have sometimes yielded satisfactory results. However, the misuse of several chemical fungicides like benzimidazoles and dicarboximides led to the development of resistant strains making more difficult the control of this pathogen [10]. New safer, environmentally friendly alternative strategies have been developed such as, biological control [11]. Several species of biocontrol agents have been isolated and are becoming increasingly interesting in controlling plant pathogens on various crops, such as Gliocladium virens, G. catenulatum [12] and Penicillium sp. [13].

As grey mold is still causing severe losses for tomato production in Tunisia, the current study focused on the use of biocontrol agents to manage B. cinerea rot on tomato fruits. Isolates of Penicillium sp. and Gliocladium spp. have been chosen as they have shown satisfactory degree of protection against several pathogens attacking tomato in Tunisia, i.e, Verticillium dahliae, Colletotrichum coccodes and Alternaria solani.

Thus, the aim of the present study is to evaluate the in vitro antifungal activity of the culture filtrates and the organic extracts of the antagonistic isolates of Penicillium sp. and Gliocladium spp. against B. cinerea and to elucidate their effect on the severity of grey mold on tomato fruits.

Materials and Methods

Pathogen

The isolate of B. cinerea used in this study was gratefully provided by the laboratory of Phytopathology of the Regional Center of Research on Horticulture and Organic Agriculture of Chott-Mariem, Tunisia. It was originally recovered from tomato cv. Rio grande fruit, showing typical symptoms of grey mold. Pathogen cultures were grown on Potato Dextrose Agar (PDA) amended with streptomycin sulphate® (300 mg/L) (Pharmadrug Production Gmbh, Hamburg, Germany) and incubated at 25°C in the dark for 7 days before use [14].

Biocontrol agents

Height isolates of Penicillium sp., one isolate of Gliocladium virens and one isolate of G. catenulatum were used in the present study (Table 1). They were isolated from compost and soil [15-17]. They were cultured on PDA and incubated at 25°C in the dark for 7 days before use [18].

Isolates Name Origin
CH5 Penicillium sp. Compost
CH6 Penicillium sp. Compost
CH7 Penicillium sp. Compost
CH9 Penicillium sp. Compost
CH11 Penicillium sp. Compost
MC1 Penicillium sp. Compost
MC3 Penicillium sp. Compost
MC4 Penicillium sp. Compost
Gv1 Gliocladium virens Soil
Gc1 Gliocladium Catenulatum Soil

Table 1: Antagonistic agents tested against Botrytis cinerea.

Fruit material

Tomato fruits (cv. Rio Grande) used for the in vivo bioassays were selected according to their maturity, firmness, consistency and especially the absence of visible symptoms of rot on their surface. Before treatment, fruits were surface disinfected with 10% sodium hypochlorite for 5 min, rinsed with sterile distilled water (SDW) and dried at ambient temperature.

Assessment of the in vitro antifungal activity of Penicillium sp. and Gliocladium spp. culture filtrates against Botrytis cinerea

Liquid culture of each antagonistic agent tested was prepared on Potato Dextrose Broth (PDB) for 28 days at room temperature under continuous stirring at 150 rpm/min [19]. A non-inoculated PDB medium served as control filtrate [20]. A volume of 20 mL was collected from each liquid culture and centrifuged thrice for 10 min at 10000 rpm. The obtained supernatant was then sterilized by filtration through 0.22 μm millipore size filter [20,21]. The control was the PDB medium filtrate. Each antagonist filtrate was aseptically added to Petri dishes containing molten PDA medium supplemented with Streptomycin sulfate (300 mg/L) at the concentration of 10% (v/v). After solidification, three 6 mm diameter-agar plugs removed from 7 days-old pathogen cultures on PDA were placed equidistantly in each Petri plate [22,23]. Fungal cultures were incubated at 25°C [23]. The mean colony diameter of the pathogen (treated and untreated control) was measured after 5 days of incubation. The mycelial growth inhibition rate was calculated using the following formula:

I% = [(C2-C1)/C2] × 100

with C2: Mean diameter of the control colony and C1: Mean pathogen colony diameter in the presence of the antagonist filtrate.

The most active culture filtrates of the tested isolates in reducing B. cinerea mycelial growth were selected and tested at three concentrations (10%, 15% and 20%, v/v) as described above.

Assessment of the in vitro antifungal activity of Penicillium sp. and Gliocladium spp. organic extracts against Botrytis cinerea

Two organic solvents, chloroform and ethyl acetate, were used to extract the antifungal metabolites produced by the tested antagonists. Only antagonist filtrates showing antifungal activity were used for this assay. Ten mL-aliquots from each antagonist filtrate, prepared as described above, were poured into a separating funnel before adding 10 mL of each extraction solvent, chloroform, or ethyl acetate [24-27]. The funnel containing this mixture was then inverted several times, by degassing from time to time, and left to settle (open cap) to quickly reach the partition equilibrium between the two phases. The organic phase (the lower phase for extraction with chloroform and the upper one with ethyl acetate) were collected. The aqueous phase was replaced in the funnel and the extraction was repeated three times. The solvent was evaporated using a rotary evaporator at 90°C with a slight rotation at 150 rpm [28-30].

In order to test their antifungal potential against B. cinerea, 1 mg of each obtained extract was dissolved in 2 mL of methanol [25,31]. These extracts were added aseptically to Petri dishes containing the culture medium (PDA) supplemented with Streptomycin sulfate (300 mg/mL) and tested at three concentrations, 1%, 2.5% and 5% (v/v). The mixture was gently stirred for a better distribution of the extract in the medium [26]. After solidification, three 6 mm-pathogen plugs obtained from 7 days-old pathogen cultures on PDA, were equidistantly placed in the Petri plate. The colony diameter of B. cinerea was measured after 5 days of incubation at 25°C.

Effect of Penicillium sp. and Gliocladium spp. culture filtrates and organic extracts on fruit grey mold severity

Disinfected tomato fruits were wounded (4 mm deep and 6 mm in diameter) at the equator using a sterile cork borer and 100 μL of each culture filtrate (of all antagonists tested) or organic extract (of the most effective culture filtrate), or SDW for the untreated control, were injected into each wound. Approximately two hours after treatment, an agar plug (6 mm in diameter) colonized by B. cinerea was placed within each wound. Treated or untreated (control) and inoculated tomato fruits were placed on moist filter papers in plastic boxes to maintain a high relative humidity and incubated at 25°C for 5 days [11]. The lesion diameter of the occasioned rot developed from inoculation sites was measured.

Statistical analysis

Statistical analysis of all measured parameters was conducted through the software SPSS 16.0 (Statistical Package for the Social Sciences) using the procedures of general linear models (GLM). The in vitro test of culture filtrates of Penicillium sp. and Gliocladium spp. was analyzed according to a completely randomized design while for the essays of culture filtrates at different concentrations and the organic extracts a completely randomized design with two factors (culture filtrates or organic extracts tested, and concentrations used) was used. Three replications were used for each elementary treatment and the whole experiment was repeated once. The in vivo tests were conducted according to a completely randomized design where the culture filtrates or organic extracts tested are the only factor studied. Each treatment was replicated five times (five fruits). Experiments were conducted two times.

All these experiments were analyzed using a standard analysis of variance (ANOVA) with interactions. Means comparisons were conducted according to the Student-Newman-Keuls (SNK) or LSD tests at P ≤ 0.05.

Results and Discussion

Effect of Penicillium sp. and Gliocladium spp. culture filtrates on the in vitro growth of Botrytis cinerea

Results shown in Figure 1 revealed that the culture filtrates of the antagonists tested exhibited significant (at P ≤ 0.05) inhibitory effect against B. cinerea, after 5 days of incubation at 25°C. The highest significant reduction of the pathogen mycelial growth, about 27%, was induced by the culture filtrate of the isolate CH6 of Penicillium sp. (Figure 2) followed by non-significant reductions, by 16%, 14%, 12% and 10% noted with filtrates of CH11 and CH5 of Penicillium sp., Gv1 of G. virens and Gc1 of G. catenulatum, respectively, as compared to the untreated control. Similar results have been reported by Di Pietro et al. [32] showing that the culture filtrate of G. virens contains metabolites such as endochitinase and gliotoxin with inhibitory effect on growth and spore germination of B. cinerea. In the same way, the culture filtrate of T. harzianum inhibited the growth of B. cinerea through chitinolytic glucanolytic, cellulolytic and xylanolytic enzymes [33]. Brunner et al. [34] also found active compounds in the culture filtrates of T. atroviride, such as glucose oxidase, able to inhibit B. cinerea spore germination. In the same sense, Chatterton [35] showed that chitinase and glucanase contained in the culture filtrate of G. catenulatum can inhibit by 50% F. oxysporum and Pythium spp. mycelial growth.

plant-pathology-microbiology-recorded-8-427-g001

Figure 1: Effect of culture filtrates of ten isolates of Penicillium sp. and Gliocladium spp. on Botrytis cinerea mycelial growth recorded after 5 days of incubation at 25°C, compared to the untreated control. FCH5, FCH6, FCH7, FCH9, FCH11, FMC1, FMC3 et FMC4: Culture filtrates of isolates CH5, CH6, CH7, CH9, CH11, MC1, MC3 et MC4 of Penicillium sp.; FGv1: Culture filtrate of isolate Gv1 of Gliocladium virens; FGc1: Culture filtrate of isolate Gc1 of G. catenulatum. Bars assigned by the same letter are not significantly different according to the Student-Newman-Keuls test at P ≤ 0.05.

plant-pathology-microbiology-morphological

Figure 2: Inhibition of the mycelial growth of Botrytis cinerea (B) and morphological alteration of its colony induced by the culture filtrate of the isolate CH6 of Penicillium sp. as compared to the untreated control (A).

Effect of three concentrations of the of the most effective culture filtrates in vitro on mycelial growth of Botrytis cinerea

Analysis of variance showed that the mean diameter of B. cinerea colonies was significantly affected by the culture filtrates of the selected antagonists and the concentrations tested, as compared to the untreated control. As shown in Figure 3, the culture filtrates of the isolates CH5 and CH6 of Penicillium sp., Gv1 of G. virens and Gc1 of G. catenulatum have significantly limited pathogen mycelial growth at the concentrations used (10%, 15% and 20% v/v) (Figure 3). The highest inhibitory effect was induced by the culture filtrate of CH6 of Penicillium sp. applied at 10%, 15% and 20% (v/v), where pathogen radial growth was reduced by 27%, 37% and 34%, respectively. Used at 15% and 20% (v/v), the culture filtrate of CH5 significantly limited pathogen growth by 4% and 17%, respectively; whereas filtrate of Gc1 of G. catenulatum reduced by 18% B. cinerea when applied at 20% (Figure 4).

plant-pathology-microbiology-culture-filtrates

Figure 3: Effect of three concentrations of culture filtrates of Penicillium sp. and Gliocladium spp. on Botrytis cinerea mycelial growth recorded after 5 days incubation at 25°C as compared to the untreated control. FCH5, FCH6: Culture filtrates of isolates CH5, CH6 of Penicillium sp.; FGv1: Culture filtrate of isolate Gv1 of Gliocladium virens; FGc1: Culture filtrate of isolate Gc1 of G. catenulatum. LSD (Culture filtrates tested × Concentrations used)=0.48 cm at P ≤ 0.05.

plant-pathology-microbiology-inhibition

Figure 4: Inhibition of Botrytis cinerea in vitro growth induced by Gc1 of Gliocladium catenulatum depending on the concentrations tested (% v/v) as compared to the untreated control.

Our findings are similar to those obtained by Zhang et al. [36] who reported that the inhibitory effect of the culture filtrates of the biocontrol agents depends on the concentrations used. In fact, they demonstrated that increasing the concentration of the filtrate obtained from Rhodotorula glutinis led to a limited incidence of the grey mold in strawberries. In the same context, Pietro et al. [32] found that the reduction of B. cinerea spore germination is correlated with the concentrations of the secondary metabolites released in the culture filtrate of G. virens. Indeed, 25 μg/mL to 50 μg/mL of endochitinase and 0.5 μg/mL to 0.75 μg/mL of gliotoxin were reported to be responsible of 95% reduction of B. cinerea mycelial growth. In the same sense, Allen et al. [37] showed that the ability of the yeast species R. glutinis to inhibit gray mold pathogen is concentrationdependent. In fact, this antifungal activity was significantly greater at the concentration of 107 yeasts/mL compared to the lower concentrations. Moreover, Chen et al. [38] found that applying five concentrations (50, 150, 250, 350 and 450 mg/L) of T. harzianum filtrate led to 73.7% reduction of F. oxysporum f. sp. cucumerinum mycelial growth. An and Ma [39] showed that 2 mL of the culture filtrate of Bacillus subtilis diluted in five doses (1%, 10%, 20%, 50% and 100%) had inhibitory effects against the development of B. cinerea at 25°C.

Antagonistic effect of organic extracts on the mycelial growth of Botrytis cinerea

Ethyl acetate extracts: Analysis of variance showed that B. cinerea colony diameter varied significantly depending on the ethyl acetate extracts tested and the concentrations used (1%, 2.5% and 5% v/v) (Figure 5). A significant interaction was recorded between both fixed factors. Indeed, when applied at 1%, the ethyl acetate extracts of CH5 and CH6 of Penicillium sp. have significantly reduced pathogen growth by 11 and 9%, respectively. Used at 2.5%, the extracts of CH5 of Penicillium sp. and Gc1 of G. catenulatum limited by 48 and 69%, respectively, the growth of B. cinerea. The highest inhibition, by 74 to 88%, was recorded with CH6, CH5, Gv1 and Gc1 extracts tested at 5% (Figure 6).

plant-pathology-microbiology-ethyl-acetate-

Figure 5: Effect of three concentrations ethyl acetate extracts from Penicillium sp. and Gliocladium spp. Botrytis cinerea mycelial growth recorded after 5 days incubation at 25°C. ECH5 and ECH6: Ethyl acetate extracts of the isolates of Penicillium sp. CH5 et CH6; EGv1: Ethyl acetate extracts of the isolates Gv1 of Gliocladium virens; EGc1: Ethyl acetate extracts of the isolates Gc1of G. catenulatum. LSD (Extracts tested × Concentrations used)=0.29 cm at P ≤ 0.05.

plant-pathology-microbiology-untreated

Figure 6: Inhibition of Botrytis cinerea in vitro growth induced by Gc1 (Gliocladium catenulatum) ethyl acetate extract depending on the concentrations tested (% v/v) as compared to the untreated control.

The antifungal potential of organic fungal extracts was reported in numerous studies as for ethyl acetate and methanolic extracts of G. virens with ability to inhibit the germination of P. ultimum oospores [32]. Furthermore, Tapwal et al. [40] demonstrated the inhibitory effect of ethyl acetate extract of Penicillium sp. used in five concentrations (1, 12.5, 25, 50 and 100 mg/mL) against some phytopathogenic species of the genus Aspergillus (A. flavus, A. versicolor and A. candidus). They also found that P. oxalicum organic extracts exhibited a significant antifungal activity against B. cinerea. These authors showed also that the appropriate solvents for extraction of Penicillium sp. secondary metabolites were ethyl acetate and hexane. Chatterton [35] found that the enzymatic extracts of G. catenulatum were found to be effective at different concentrations in reducing the conidial germination of F. oxysporum and in inhibiting growth of Pythium species. Vio-Michaelis et al. [41] have recently reported the inhibitory effect of ethyl acetate, n-hexanoic, n-butanol, methanolic and ethanolic extracts of the Ephedra breana plants and Nolana sedifolia on mycelial growth of B. cinerea at the concentration 250 μg/mL. The acetone crude extracts of the fungi strain Basidiomycetes also inhibited in vitro the colony growth of B. cinerea [42].

Chloroform extracts: Analysis of variance revealed a significant effect (P ≤ 0.05) of the chloroform extracts tested and the concentrations used as well as their interaction on B. cinerea radial growth. Tested at 1% (v/v), the chloroform fractions of CH5 of Penicillium sp. and Gc1 of G. catenulatum have significantly reduced pathogen mycelial growth by 16 and 9%, respectively. Applied at 2.5%, chloroform extracts obtained from Gc1 and Gv1 cultures were more active, showing respectively 88 and 81% inhibition of pathogen mycelial growth, than those from Penicillium sp. isolates, CH5 and CH6, reducing growth by 53 and 45%. Used at 5%, extracts of Gv1 (G. virens), Gc1 (G. Catenulatum) and CH6 (Penicillium sp.) have significantly limited B. cinerea colony diameter by 88, 84 and 81%, respectively (Figure 7) as compared to the untreated control.

plant-pathology-microbiology-chloroform

Figure 7: Effect of three concentrations of chloroform extracts from Penicillium sp. and Gliocladium spp. isolates tested at against Botrytis cinerea mycelial growth recorded after 5 days incubation at 25°C. ECH5 and ECH6: Chloroform extracts of the isolates of Penicillium sp. CH5 and CH6; EGv1: Chloroform extract of the isolate Gv1 of Gliocladium virens; EGc1: Chloroform extract of the isolate Gc1 of G. catenulatum. LSD (Extracts tested × Concentrations used)=0.29 cm at P ≤ 0.05.

Similar results were obtained by Iftikhar and Alam [31] with the ethyl acetate and chloroform extracts of T. harzianum used against F. oxysporum f. sp. ciceris. Indeed, a significant inhibition of B. cinerea growth has been recorded with the two types of extracts due to the presence of antifungal metabolites in their culture filtrates. Other studies have highlighted the ability of the chloroform extracts of P. janthillium and P. duclauxii to inhibit spore germination and mycelial growth of Grifola umbellate due to the secondary metabolites present in their culture filtrates [30]. In the same way, according to Fu et al. [27], the chloroform extracts of Phomopsis sp. are able to significantly inhibit the growth of B. cinerea in vitro at different concentrations (3.125, 6.25, 12.5, 25, 50, 100 and 200 μg/mL) (Figures 8 and 9).

plant-pathology-microbiology-chloroform

Figure 8: Inhibition of Botrytis cinerea in vitro growth induced by CH6 of Penicillium sp. chloroform extract depending on the concentrations tested (% v/v) as compared to the control.

plant-pathology-microbiology-extract

Figure 9: In vitro inhibition of Botrytis cinerea growth induced by chloroform extract from Gv1of Gliocladium virens depending on the concentrations tested (% v/v) as compared to the control.

Effect of the culture filtrates on grey mold severity

The culture filtrates of Penicillium sp. and Gliocladium spp. isolates were tested on tomato fruits before their inoculation with B. cinerea. Anova analysis showed a significant variation (P ≤ 0.05) of the grey mold lesion diameter by the tested culture filtrates. Indeed, lesion diameter recorded after incubation at 25°C was reduced by 53, 52 and 50%, with the culture filtrates of MC1, CH11 of Penicillium sp. and Gv1 of G. virens (Figure 10), respectively, as compared to the untreated control. The culture filtrates of CH7, CH6 and CH5 of Penicillium sp. significantly limited disease severity by 35 to 37% compared to 23 and 26% noted with culture filtrates of MC3 of Penicillium sp. and Gc1 of G. catenulatum, respectively (Figure 11).

plant-pathology-microbiology-mold-severity

Figure 10: Effect of the culture filtrates of Penicillium sp. and Gliocladium spp. tested on grey mold severity on tomato fruits recorded after 5 days of incubation at 25°C compared to the inoculated and untreated control fruits. FCH5, FCH6, FCH7, FCH9, FCH11, FMC1, FMC3 et FMC4: Culture filtrate of isolates CH5, CH6, CH7, CH9, CH11, MC1, MC3 et MC4 of Penicillium sp.; FGv1: Culture filtrate of isolate Gv1 of Gliocladium virens; FGc1: Culture filtrate of the isolate Gc1 of G. catenulatum. Bars assigned with the same letter are not significantly different according to the test Student-Newman-Keuls at P ≤ 0.05.

plant-pathology-microbiology-grande

Figure 11: Effect of the culture filtrate of Gv1 of Gliocladium virens on grey mold severity on tomato cv. Rio grande fruits (B) compared with the untreated and inoculated control (A). N.B. The black dots are added to define the dimensions of the grey mold lesions on inoculated and treated fruits.

Similar effects were observed by Bridžiuvienė and Repečkienė [43] on grape bunches infected by B. cinerea and treated with the culture filtrates of T. virens. These authors also demonstrated the effectiveness of the culture filtrate of Penicillium sp. in the control of this pathogen. In the same sense, Burgess et al. [44] reported the protection of chickpea against B. cinerea using G. roseum culture filtrate. Similarly, filtrates of T. harzianum were shown to be effective in limiting by 52% the lesion diameter on B. cinerea-inoculated tomato fruits, five days after inoculation [33]. In the same way, Zhang et al. [36] demonstrated the antifungal activity of Rhodotorula glutinis towards B. cinerea infecting stored strawberries. Similar results were reported in the in vitro studies of Card [12] concerning the efficiency of G. catenulatum culture filtrate and its variable activity depending on the site of its application and the source of contamination with B. cinerea. Therefore, the greater distance of the application of G. catenulatum for increasing their protective effect was very low to the site of infection. The inhibitory effects were reported by Abou-Zeid et al. [45] where the filtrates of G. deliquescens and G. virens exhibited a strong suppressive potential of the severity of diseases caused by A. alternata and F. oxysporum on some medicinal plants as Prunus peorsica and Pulicaria crispa.

It should be also noted that all the culture filtrates tested could not completely inhibit the growth of B. cinerea on the site of inoculation but only decreased the diameter of the lesions on tomato fruits, compared to the control. Thus, pathogen sporulation depreciates the quality of the treated tomato fruits. The evaluation of the antifungal potential of the extracts from culture filtrates may give more interesting inhibitory effects.

Antagonistic effect of the organic extracts on grey mold severity

Suppressive effect of ethyl acetate extracts: Ethyl acetate extracts of Penicillium sp. and Gliocladium spp. were assessed for their potential to control B. cinerea infection on tomato fruits. Analysis of variance revealed that grey mold lesion diameter noted on inoculated and treated fruits varied significantly (P ≤ 0.05) depending on treatments tested. Ethyl acetate extracts of CH5 and CH6 of Penicillium sp. were found the most effective in reducing disease severity by 45% and 64%, respectively compared to inoculated and untreated control (Figure 12). Moreover, the tested extracts completely suppressed B. cinerea mycelial growth at the fruit inoculation site. Thus, these extracts were shown to possess promising antifungal active compounds for controlling B. cinereal (Figure 13).

plant-pathology-microbiology-grey-mold

Figure 12: Effect of the ethyl acetate extract from Penicillium sp. and Gliocladium spp. tested on grey mold severity on tomato fruits recorded after 5 days of incubation at 25°C, compared to the inoculated and untreated control. ECH5 and ECH6: Ethyl acetate extracts of the isolates of Penicillium sp. CH5 et CH6; EGv1: Ethyl acetate extracts of the isolates Gv1 of Gliocladium virens; EGc1: Ethyl acetate extracts of the isolates Gc1of G. catenulatum.. Bars assigned the same letter are not significantly different according to the test Student-Newman-Keuls at P ≤ 0.05.

plant-pathology-microbiology-ethyl-acetate

Figure 13: Effect of the ethyl acetate extract of the isolate CH6 of Penicillium sp. on grey mold severity (B) compared with the inoculated and untreated control (A). N.B. The black dots are added to define the dimensions of the grey mold lesions on inoculated and treated fruits.

Suppressive effect of chloroform extracts: The chloroform extracts of the antagonists tested were also evaluated for their inhibitory effect on the development and severity of grey mold on tomato fruits. Analysis of variance showed that the external lesion diameter varied significantly (P ≤ 0.05) between treatments tested. As shown in Figure 14, only chloroform extracts of CH5 of Penicillium sp. and Gc1 of G. catenulatum have significantly reduced the severity of the decay by 67% and 17%, respectively. The other extracts tested were founded to be ineffective in controlling the disease and behaved as the untreated control. Furthermore, these extracts, as already recorded with the ethyl acetate ones, completely inhibited B. cinerea mycelial growth and sporulation at the infection site. Similar inhibitory effects were also obtained with aqueous extracts of Trichoderma sp. found to be able to control B. cinerea on tomato plants [46] (Figure 15).

plant-pathology-microbiology-significantly

Figure 14: Effect of the chloroform extract from Penicillium sp. and Gliocladium spp. tested on grey mold severity on tomato fruits recorded after 5 days of incubation at 25°C compared to the inoculated and untreated control. ECH5 and ECH6: Chloroform extracts of the isolates of Penicillium sp. CH5 and CH6; EGv1: Chloroform extract of the isolate Gv1 of Gliocladium virens; EGc1: Chloroform extract of the isolate Gc1 of G. Catenulatum. Bars assigned with the same letter are not significantly different according to the test Student-Newman-Keuls at P ≤ 0.05.

plant-pathology-microbiology-untreated-control

Figure 15: Effect of the chloroform extract of CH5 of Penicillium sp. on grey mold severity (B) compared with the inoculated and untreated control (A). N.B. The black dots are added to define the dimensions of the grey mold lesions on inoculated and treated fruits.

Conclusion

The present study investigates the suppressive effects of different culture filtrates and organic extracts of Penicillium sp. and Gliocladium spp. isolates on the in vitro growth of B. cinerea and toward the grey mold severity on tomato fruits.

The use of culture filtrates or organic extracts of the biocontrol agents Penicillium sp. and Gliocladium spp. against grey mold pathogen have shown encouraging results in vitro and led to a significant reduction of the mycelial growth of the pathogen, essentially with CH6 (Penicillium sp.) and Gc1 (G. catenulatum). Overall, the increase in the rate of inhibition of the pathogen was positively correlated with the increase of the concentration of the culture filtrate or extract used.

These results recorded in vitro were also evaluated in vivo using these biocontrol agents for the treatment of tomato fruits inoculated with B. cinerea. Culture filtrates of CH11, MC1 of Penicillium sp. and Gv1 of G. virens were found to be the most effective in reducing disease severity. Moreover, the use of ethyl acetate and chloroform extracts against B. cinerea showed that CH5 and CH6 of Penicillium sp. and Gc1 of G. catenulatum were effective in controlling of the disease.

Therefore, this application of antagonists is considered as a promising approach that can reduce the use of synthetic fungicides and their negative impact on the consumer and the environment. Furthermore, it would be interesting to study the efficiency of the bioactive metabolites contained in the aqueous phase of the antagonist tested, to elucidate the main compounds in the culture filtrates and their mechanisms of action and to promote these isolates as biological control agents against other tomato diseases.

Acknowledgements

This work was funded by the Ministry of Higher Education and Scientific Research of Tunisia through the funding allocated to the research unit UR13AGR09-Integrated Horticultural Production in the Tunisian Centre-East. My sincere gratitude goes to all the staff of the Regional Centre of Research in Horticulture and Organic Agriculture (CRRHAB) for their welcome and pleasant working conditions.

References

  1. Finkers R (2007) The genetics of Botrytis cinerea resistance in tomato. Thesis, University of Wageningen, Netherlands. p. 126.
  2. Arunakumara KT (2006) Studies on Alternaria solani (Ellis and Martin) Jones and Grout causing early blilght of tomato. Master, University of Agricultural Sciences, Dharwad, India. p. 70.
  3. Hommel M (2007) Transcriptional regulation of gene expression in tomato fruit: Functional characterization of fruit-specific promoters and a MBF1 type transcription factor. Thesis, National Polytechnic Institute of Toulouse, France. p. 145.
  4. Messaï A, Hannachi C, Zid E (2006) In vitro regeneration of tomato plants (Lycopersicon esculentum Mill.) adapted to NaCl. Tropicultura 24: 221-228.
  5. Ibrahim AD, Hussaini H, Sani A, Aliero AA, Yakubu SE (2011) Volatile metabolites profiling to discriminate diseases of tomato fruits inoculated with three toxigenic fungal pathogens. Res Biotechnol 2: 14-22.
  6. Foulds IV (2000) The role of hydrogen peroxide in the resistance of tomato to penetration by Colletotrichum coccodes. Master, University of Toronto, Canada. p. 84.
  7. Magnin-Robert M (2007) Protection of the vine against Botrytis cinerea and stimulation of defense mechanisms using bacteria from the Champagne vineyards. Thesis, University of Reims Champagne-Ardenne, France. p. 198.
  8. Badawy MEI, Rabea EI (2009) Potential of the biopolymer chitosan with different molecular weights to control postharvest grey mold of tomato fruit. Postharvest Biol Technol 51: 110-117.
  9. Li GQ, Huang HC, Acharya SN, Erickson RS (2004) Biological control of blossom blight of alfalfa caused by Botrytis cinerea under environmentally controlled and field conditions. Plant Dis 88: 1246-1251.
  10. Hmouni A, Hajlaoui MR, Mlaiki A (1996) Resistance of Botrytis cinerea to benzimidazoles and dicarboximides in tomato crops in Tunisia. OEPP /EPPO Bulletin 26: 697-705.
  11. Mónaco C, Bello D, Rollán MC, Ronco L, Lampugnani G, et al. (2009) Biological control of Botrytis cinerea on tomato using naturally occurring fungal antagonists. Arch Phytopathol Plant Prot 42: 729-737.
  12. Card SD (2005) Biological control of Botrytis cinerea in lettuce and strawberry crops. Thesis, Lincoln University, New Zealand.
  13. Senthilkumar G, Madhanraj P, Panneerselvam A (2011) Studies on the compounds and its antifungal potentiality of fungi isolated from paddy field soils of Jenbagapuram village, thanjavur district, and south India. Asian J Pharmaceutical Res 1: 19-21.
  14. Maatougui MEH, Merzoug A (1997) Study on Botrytis fabae Sard: Optimal conditions of in vitro culture on three isolates collected in western Algeria and test of the reaction of bean and faba bean genotypes: Mediterranean food legumes. INRA, Paris, France.
  15. Ayed F, Daami-Remadi M, Jabnoun-Khiareddine H, El-Mahjoub M (2006) Potato vascular wilt in Tunisia: Incidence and biocontrol by Trichoderma spp. Plant Pathol J 5: 92-98.
  16. Daami-Remadi M (2006) Study of fusariosis of the potato. Thesis, Chott Mariem Higher School of Horticulture and Breeding, University of Sousse, Tunisia.
  17. Jabnoun-Khiareddine H (2011) Verticilliose of vegetable crops in Tunisia: Importance, morphological, pathogenic and physiological characterization of Verticillium spp., Varietal behavior and biological control. Thesis, Higher Agronomic Institute of Chott-Mariem, University of Sousse, Tunisia.
  18. Comporta P (1985) In vitro Antagonism of Trichoderma spp. vis-à-vis Rhizoctonia solani Kühn. Agronomie 5 :613-620.
  19. Dennis C, Webster J (1971) Antagonisme properties of species of Trichoderma: Production of volatile antibiotics. Transactions Brit Mycol Soci 57: 41-48.
  20. Lepengue NA, Mouaragadja I, M’Batchi B, Ake S (2009) Study of some physico-chemical characteristics of the toxic filtrate of Phoma sabdariffae Sacc., Pathogen of the roselle. Sci Nat 6: 95-105.
  21. El-Katatny MH, Gudelj M, Robra KH, Elnaghy MA, Gübitz GM (2001) Characterization of a chitinase and an endo-β-1,3-glucanase from Trichoderma harzianum Rifai T24 involved in control of the phytopathogen Sclerotium rolfsii. App Microbiol Biotechnol 56: 137-143.
  22. Abdel-Sater MA (2001) Antagonistic interactions between fungal pathogen and leaf surface fungi of onion (Allium cepa L.). Pak J Biol Sci 4: 838-842.
  23. Mishra VK (2010) In vitro antagonism of Trichoderma species against Pythium aphanidermatum. J Phytol 2: 28-35.
  24. Atoui AK (2006) Mycotoxinogenesis approach in Aspergillus ochraceus and Aspergillus carbonarius: Molecular and physiological studies. Thesis, National Polytechnic Institute of Toulouse, France.
  25. You F, Han T, Wu J, Huang B, Qin L (2009) Antifungal secondary metabolites from endophytic Verticillium sp. Biochem Syst Ecol 37: 162-165.
  26. Smoui S (2010) Purification and characterization of biomolecules from newly isolated and identified microorganisms. Thesis, National Polytechnic Institute of Toulouse, University of Toulouse, France.
  27. Fu J, Zhou Y, Li HF, Ye YH, Guo JH (2011) Antifungal metabolites from Phomopsis sp. By254, an endophytic fungus in Gossypium hirsutum. Afr J Microbiol Res 5: 1231-1236.
  28. Salaün S (2009) Interactions between brown macroalga Laminaria digitata and its bacterial epibionts: Molecular and spectroscopic studies, and adhesion and biofilm formation capacity. Thesis, Doctoral School Health Information Communication Matter and Mathematics, University of Southern Brittany, France.
  29. Abdel-Motaal FF, Nassar MSM, El-Zayat SA, El-Sayed MA, Ito SIC (2010) Antifungal activity of endophytic fungi isolated from egyptian henbane (Hyoscyamus Muticus L.). Pak J Bot 42: 2883-2894.
  30. Zain ME, El-Sheikh HH, Soliman HG, Khalil AM (2011) Effect of certain chemical compounds on secondary metabolites of Penicillium janthinellum. J Saudi Chem Soci 15: 239-246.
  31. Iftikhar AK, Alam S (2001) Detection of antifungal compounds from antagonistic microorganisms inhibiting the growth of Fusarium oxysporun f. sp. Ciceris. Pak J Bot 33: 659-662.
  32. Di Pietro A, Lorito M, Hayes CK Broadway RM, Harman GE (1993) Endochitinase from Gliocladium virens: Isolation, characterization, and synergistic antifungal activity in combination with gliotoxin. Phytopathol 83: 308-313.
  33. Ambrosino P, Prisco R, Ruocco M, Lanzuise S, Ritieni A, et al. (2005) Biological control of apple and tomato post-harvest diseases caused by Botrytis cinerea and Alternaria Alternata by using culture filtrates of Trichoderma harzianum. J Plant Pathol 87: 267-309.
  34. Brunner K, Zeilinger S, Ciliento R, Woo SL, Lorito M, et al. (2005) Improvement of the fungal biocontrol agent Trichoderma atroviride to enhance both antagonism and induction of plant systemic disease resistance. Appl Env Microbiol 71: 3959-3965.
  35. Chatterton S, Punja ZK (2009) Chitinase and β-1,3-glucanase enzyme production by the mycoparasite Clonostachys rosea f. catenulata against fungal plant pathogens. Can J Microbiol 55: 356-367.
  36. Zhang H, Li R, Liu W (2011) Effects of chitin and its derivative chitosan on postharvest decay of fruits: A Review. Int J Mol Sci 12: 917-93.
  37. Allen TW, Burpee LL, Buck J (2004) In vitro attachment of phylloplane yeasts to Botrytis cinerea, Rhizoctonia solani, and Sclerotinia homoeocarpa. Rev Can Microbiol 50: 1041-1048.
  38. Chen LH, Cui YG, Yang XM, Zhao DK, Shen QR (2012) An antifungal compound from Trichoderma harzianum SQR-T037 effectively controls Fusarium wilt of cucumber in continuously cropped soil. Aust Plant Pathol 41: 239-245.
  39. An RP, Ma Q (2006) Control of cucumber grey mold by endophytic bacteria. Cucurbit Genetics Cooperative Reports 28-29: 1-6.
  40. Tapwal A, Singh U, Teixeira da Silva JA, Singh G, Garg S, et al. (2011) In vitro antagonism of Trichoderma viride against five phytopathogens. Pest Technol 5: 59-61.
  41. Vio-Michaelis S, Apablaza-Hidalgo G, Gómez M, Peňa-Vera R, Montenegro G (2012) Antifungal activity of three Chilean plant extracts on Botrytis cinerea. Bot Sci 90: 172-183.
  42. Adongo JO, Njue AW, Omolo JO, Cheplogoi PK, Otaye DO (2012) In vitro inhibition of Botrytis cinerea- causative agent for grey mold by crude extracts of Basidiomycetes fungi. Sci J Biochem 2012: 1-3.
  43. Bridžiuvienė D, Repečkienė J (2009) Interspecific relation peculiarities between soil and phytophatogenic fungi. Scientific Works of the Lithuanian institute of Horticulture and Lithuanian, University of Agriculture 28: 19- 28.
  44. Burgess DR, Bretag D, Keane PJ (1997) Biocontrol of seedborne Botrytiss cinerea in chickpea with Gliocladium roseum. Plant Pathol 46: 298-305.
  45. Abdou-Zeid AM, Altalhi AD, Abd El-Fattah RI (2008) Fungal control of pathogenic fungi isolated from some wild plants in Taif governorate, Saudi Arabia. Malays J Microbiol 4: 30-39.
  46. Abadi KM (2008) Novel plant bio-protectants based on Trichoderma spp. strains with superior characteristics. Thesis, University of Naples "Federico II", Italie.


Copyright: This is an open access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
