Sheep were the earliest stock with the procreative potency over different stock like cows and horses [1]. A most of 70-80% fertility estimates in giant stock wherever fertility rates of 100 percent are regular options in sheep and goats. The trendy day techniques like secretion elicited super-ovulation, organic process detection and embryo manipulations, embryo culture, synchronizations, in vitro fertilization, have culminated into a surprise animal “Dolly”, the sheep, on the fifth of July 1996, that was a milestone within the history of biotechnology.

Cloning, deoxyribonucleic acid injections and improvement in productivity through biotechnology [2] approaches has entered into advanced analysis and far info on the utilization of pre-implantation in sheep embryo production for keeps saving biological is on the market. It’s a positive gesture in development of reproductive efficiency in sheep and further research has to be established in embryo development. The production of endocrine wealthy milk from goats and blood platelet activating factors production square measure a number of the mile stones of immense increasing biotechnological inventions in bovid replica.

The recovering oocytes subjected to in vitro maturation (IVM), in vitro fertilization (IVF) and in vitro culture (IVC) for 7 days using standard procedures for sheep. Some factor(s) within the culture media, like growth factors within the sera, could have a mitogenic impact on embryonic cells, or it should alter the distribution of cells to the trophectoderm and inner cell mass, leading to increased body growth rates [3,4].

The influence of assorted in vitro procedures on embryo survival and therefore the production of traditional offspring were investigated in sheep [5]. IVM and IVF provided serial embryonic and vertebrate development in sheep no matter the resultant in vivo or in vitro culture treatments. Attachment procedures square measure a lot of cytotoxic for vesicle survival than cryopreservation. Though this, process is resumed in the sheep and none of the sheeps grafted orthotopically became fertile at a synchronised conjugation [6]. Seven months following attachment, oocytes will be collected from heterotopic and orthotopic grafts, matured and a few of them fertilized. This method is also not developed to the blastodermic vesicle stage. Hence, heterotopic attachment could also be another to orthotopic attachment to preserve fertility provided vesicle survival within the grafts has been markedly improved.

IVM, IVF and IVC provide the established procedures for bovine in vitro embryo production throughout main breeding season are conducted on Reindeer oocytes [7]. When 24 h of maturation and cumulus enlargement was complete, 71% of the oocytes reached Metaphase II (MII) with extrusion of the primary cell. The chances of fertilization and cleavage in Reindeer oocytes were found as 36% and 31.8%. During fertilization, two oocytes developed to the morula stage after 7 days of culture

The influence of varied in vitro procedures on embryo survival and therefore the production of traditional offspring were investigated in sheep has been incontestable [5]. The impact of supply of cumulusoocytes- complexes (COCs), maturation and fertilization conditions on biological process ability of Camelus dromedarius embryos was examined and Quality of the ocytes was assessed through IVM, IVF and IVC of COCs [8]. The COCs percentage reaching metaphase II (MII) after 30 h of maturation was slightly however not considerably higher for in vivo matured oocytes (93%) than those in vitro matured oocytes (84%).

The present study investigates the production of embryos through IVM/IVF/IVC procedures. The compositions in various culture media differ significantly and the production may vary. Hence the effect of proteins and effect of vitamin E during IVC has to be conducted to improve the production of oocytes and embryos during embryo production.

Collection, transportation and retrieval of ovaries

Irrespective of age and body condition, the ovaries from sheep were collected from slaughter of Chennai corporation abattoir. The ovaries were selected and brought to the laboratory in a very thermos containing normal saline maintained at 37°C and supplemented with 10 μl/ml penicillin-streptomycin.

The extra ovarian tissues were cut off and therefore the ovaries were washed completely beneath running tap water and rinsed five times in normal saline. The ovaries were then kept in a sterile beaker that contains normal saline at 37°C. The Oocytes were then retrieved by slicing method that has been proposed by Wani et al. [9]. The COCs were then screened using a stereo zoom microscope and transferred into a 35 mm petridish containing fresh oocyte collection medium.

Classification and grading of oocytes

Grading of the oocytes was done on the basis of cumulus cells investment and homogeneity of cytoplasm according to Wani et al. [9].

Grade A (Good): Those with over 3 layers of cumulus cells encompassing the oocyte and uniform cytoplasm.

Grade B (Fair): Those with less than 3 layers of cumulus cells encompassing the oocyte and uniform cytoplasm.

Grade C (Poor): Those with no cumulus cells surrounding the oocyte

Effect of various protein supplements on embryo development

Animal protein supplements and its replacement with plant peptones during IVM, IVF and subsequent embryo development of the ovine oocytes has been designed and evaluated. In each group six replicates were carried out.

Group I: 10% FBS in maturation, fertilization and culture media [10].

Group II: Maturation, fertilization and culture media with 5 mg/ ml BSA-FAF [11].

Group III: 0.18 mg/ml wheat peptones in maturation, fertilization and culture media [12].

Influence of various protein supplements on nuclear maturation of ovine oocytes

The animal protein supplements and its replacement with plant peptones during IVM in TCM 199 containing hormones (FSH, LH and estradiol) and epidermal growth factor (EGF) has been designed and evaluated. In each group six replicates were carried out.

Group IV: COCs were matured in the maturation medium that is supplemented with 10% fetal bovine serum (FBS)

Group V: COCs were matured in the maturation medium that is supplemented with 5 mg/ml bovine serum albumin-fatty acid free (BSA-FAF)

Group VI: COCs were matured in the maturation medium that is supplemented with 0.18 mg/ml wheat peptones

Assessment of nuclear maturation

To determine the nuclear maturation oocytes were stained with Hoechst 33342 (bisBenzimide H33342 trihydrochloride) stain.

Staining of the oocytes with 10 μg/ml Hoechst 33342 for 10 min, placed between slide and coverslip, were examined under Leica microscope equipped with fluorescent illumination (UV 2-A filter block, 330-380 nm excitation and 420 nm emission) for second metaphase stage (MII) oocytes. Maturation of the oocytes is assessed by observing extruded first polar body. From the matured COCs, cumulus cells were removed by vortexing.

In vitro maturation of oocytes

The IVM medium TCM-199 is supplemented with 0.02 IU/ml of luteinizing hormone (LH), 100 ng/ml EGF, 1 μg/ml of follitropin (FSH), 1 μg/ml of estradiol and 10 μl/ml penicillin-streptomycin. To the medium, 10% FBS, 5 mg/ml BSA and 0.18 mg/ml wheat peptones were supplemented separately in maturation medium to assess the maturation rate. Nearly 50 μl of IVM droplets is prepared in a Petri dish that is overlaid with mineral oil and pre-equilibrated in CO₂ incubator for a minimum of 2 h at 38.5°C under 5% CO₂.

The graded and selected oocytes are washed four times in the maturation medium. In a static platform, nearly 10 COCs are transferred to each droplet and allowed to mature at 38.5°C in humidified atmosphere under 5% CO₂ for 24 h. 10 ml of maturation medium was prepared freshly before each trial.

Assessment of maturation of oocytes

The degree of maturation is assessed based on cumulus cell expansion through examination of oocytes under stereo zoom microscope.

Degree 2: The cumulus cells were spread homogenously and clustered cells were no longer present (Full cumulus cell expansion).

Degree 1: The cumulus cells were spread non-homogenously and clustered cells were still present (Moderate cumulus cell expansion).

Degree 0: The cumulus cells are highly adhering to the zona pellucida (Slight or no expansion).

Degree 1 and 2 cumulus expansion oocytes were considered as matured and the maturation rate was expressed as percentage of the total number of oocyte cultured.

Source of semen

Testis from slaughtered adult rams (one year and above) were washed thoroughly in tap water and transported in a flask containing PBS supplementation with 50 μg/ml gentamicin to the laboratory within 30 min and used as source of semen.

Collection of cauda epididymal sperm

The tunica albugenia was removed and the testis was washed thoroughly with tap water and PBS. The cauda epididymis was cleaned with 70% alcohol. Then the cauda is incised deeply with Bard-Parker blade and the gushing fluid, rich in sperms was flushed into petridish containing sperm wash medium is assessed before processing.

Preparation of motile sperm for fertilization

The testis was trimmed and the tail of the epididymis likely to contain mature sperm was cut using a sterile blade. The sperm-rich fluid oozed out is directly placed on BSA-free Brackett and Oliphant (BSA free BO) medium (contains 10 μg/ml Heparin and 10 mM caffeine sodium benzoate) in a Petri dish. Sperm selection was carried out in a Percoll density gradient (45/90%) placed in CO₂ incubator at 39°C for 2 h. Approximately 2-3 ml of BSA free BO medium containing the semen sample was layered over the pre-incubated gradient solution in sterile centrifuge tubes, and centrifuged at 1400 rpm for 10 min at room temperature.

The supernatant was discarded and the sperm sediment is to be rewashed three times by centrifugation at 1400 rpm for 10 min in BSAfree BO medium. The final pellet is resuspended in 1 ml of BSA-free BO medium diluted with 1 ml of BO medium containing 20 mg/ml of BSA supplemented with 10 μg/ml heparin. A final sperm concentration of 1 to 2×10⁶ per ml BO medium was used for fertilization. Mature sheep COCs is then washed in BO medium and distributed at the rate of 20/100 μl drop of fertilization medium under mineral oil.

Preparation of fertilization droplets

Capacitated spermatozoa (2 μl) were added to the fertilization drops and incubated for 18 h at 38°C at 5% CO₂.

Morphological evaluation for development of embryos

In all the experimental groups, cleavage rate was assessed at 48 h of culture and subsequent embryo development was assessed every 24 h post insemination up to 5-6 days. The number of embryos at various stages (2-, 4-, 8- and 16- celled) and morula were recorded.

Effect of various protein supplements

In vitro developmental rates of ovine zygotes were compared in culture media that are supplemented separately with FBS, BSA and wheat peptones.

The IVM is assessed in TCM-199 supplemented with 1 μg/ml of FSH, 0.02 IU/ml of LH, 1 μg/ml of estradiol, 100 ng/ml EGF and 10 per cent FBS and IVF was done using Fertilization-Tyrode Albumin Lactate and Pyruvate (IVF-TALP) medium supplemented with BSA. In each group six replicates were carried out.

Group VII: 10% FBS in culture media

Group VIII: 5 mg/ml BSA-FAF in culture media

Group IX: 0.18 mg/ml wheat peptones in culture media

In all the experimental groups, cleavage rate was assessed at 48 h of culture and subsequent embryo development was assessed every 24 h post insemination up to 5-6 days. The number of embryos at various stages viz. 2-, 4-, 8-16 cell and morula were recorded.

Effect of culture media for development of embryos

Various media are prepared and the concentrations were standardized. Various media were added to oocyte maturation medium followed by culture in 20% O₂ environment.

TCM-199

The composition of TCM-199 has been presented in table 1.

Table 1: The composition of TCM-199.

The TCM-199 media contains various micro and macro elements along with amino acids and Vitamins. These components act as the source of embryo development. Availability of vitamins in lower levels may not be sufficient at normal conditions.

Preparation of standards can be done using following procedures

• ITS (Insulin Transferrin Sodium Selenite

1. Let the vial with ITS equilibrate to room temperature

2. Dissolve the Its in 5 ml sterile water after dissolve the ITS in 5 ml sterile water and keep it at room temperature for 30-60 min.

3. Aliquot (10 μl portions) and store at -20°C (6 Months).

• EGF (Epidermal Growth Factor)

1. Let he vial with EGF equilibrate to room temperature

2. Wip top of vial with 70% ethanol

3. Add 10 ml 0.9% NaCl using a syringe and needle to the vial and dissolve

4. Aliquot (50 μl portions) and store at -20°C (2 months) with 10 ng/μl.

• Gentamycin

Gentamycin 50 mg/ml normal saline, stored in refrigerator.

TCM-199+

Composition of TCM-199+has been shown in table 2.

Table 2: Composition of TCM-199+.

• Preparation: Add the components as per the above concentration filter using Millipore and pour into 5 ml conical tube. Store the medium at 0 to 4°C for one week.

TCM-199-

Composition of TCM-199-has been shown in table 3.

Table 3: Composition of TCM-199-.

• Preparation: Add the components as per the above concentration filter using Millipore and pour into 5 ml conical tube. Store the medium at 0 to 4°C for 1 week.

CR1aa

Composition of CR1aa has been shown in table 4.

Table 4: Composition of CR1aa.

• Preparation: Add the components as per the above concentration filter using Millipore and pour into 5 ml conical tube. Store the medium at 0 to 4°C for 1 week.

Effect of culture media with vitamins on embryo development

α-tocopherol separately at 0, 50, 100, 200 and 400 μM concentrations were added to oocyte maturation medium followed by culture in 20% O₂ environment. The formulation of media with α-tocopherol has been experimented for better understanding of requirement in embryo development.

Statistical analysis

Statistical analysis of data was done according to the Snedecor and Cochran method [12]. The percentage mean value of standard error (mean % ± S.E) was calculated for fertilization rates of oocytes and developmental rates of the embryonic stages.

Recovery rate of different grades of ovine oocytes by slicing technique

The number and recovery rate of ovine oocytes following slicing technique is presented. Using slicing technique, around 1,407 oocytes were isolated from 341 sheep ovaries with an average of 4.13 oocytes per ovary. By slicing technique 546 (38.81%), 648 (46.06%) and 213 (15.14%) oocytes has been classified as grade A, B and C respectively (Figure 1).

Figure 1: Percentage of different grades of Ovine oocytes recovered by slicing technique.

Influence of protein supplements and analyzing maturation rate of ovine oocytes

The effect of animal protein supplements and its replacement with plant peptones during IVM of ovine oocytes is presented. Out of 206 oocytes cultured in Group I, 184 oocytes matured with a mean maturation percentage of 89.32 ± 1.67. Out of 196 oocytes cultured in Group II, 157 oocytes matured with a mean maturation percentage of 80.10 ± 1.64. Out of 199 oocytes cultured in Group III, 108 oocytes matured with a mean maturation percentage of 54.27 ± 1.81 (Figure 2).

Figure 2: Maturation rate of ovine oocytes in media supplemented with various proteins.

The maturation rate of oocyte was significantly higher in the FBS supplemented group when compared with BSA and wheat peptone supplemented groups.

The observation of matures and immature ovaries and the final observation of matures single polar body has been shown from figure 3.

Note: A. Immature oocyte B. Mature oocyte has been represented after removing cumulus cells for observation of single polar body in oocyte

Figure 3: Mature and Immature Oocytes.

Effect of protein supplements on IVF and subsequent embryo development

The in vitro fertilization and developmental rates of ovine oocytes under three different protein supplements are presented in table 5. The number of oocytes produced from FBA, BSA and Wheat peptones from six replicates are 184, 157 and 108 respectively. The fertilization rates in media supplemented with FBS is found significant compared to BSA+FAF or Wheat peptones (Table 5).

Table 5: Mean ± S.E. percentage of fertilization rate and embryo development of ovine-oocytes in media supplemented with various proteins.

Figure 4 shows the isolation and identification of sperms, fertilization and final occurrence of two celled embryos. The fertilized oocytes with six replicates has observed highest fertilization rate in FBS (75.00 ± 1.88) compared with the other two protein supplements rich as BSA (52.87 ± 2.04) and wheat peptones (44.44 ± 0.77).

Figure 4: Sperm isolation and Fertilization.

Effect of protein supplements in IVC media on subsequent embryo development

The developmental rates of presumptive zygotes under different supplements are presented. In the FBS supplemented group (Group VII), the developmental rates of 2-, 4-, 8-16 cell and morula stages were 73.58 ± 2.92, 58.77 ± 2.01, 41.22 ± 1.68 and 20.17 ± 0.76 per cent (mean ± SE), respectively. In BSA-FAF group (Group VIII), the developmental rates of 2-, 4-, 8-16 cell and morula stages were 74.22 ± 2.56, 60.93 ± 2.55, 42.97 ± 2.20 and 24.21 ± 1.28 per cent (mean ± SE), respectively. In wheat peptones group (Group IX), the developmental rates of 2-, 4-, 8-16 cell and morula stages were 72.89 ± 1.09, 57.01 ± 0.76, 42.05 ± 0.36 and 24.29 ± 0.55 per cent (mean ± SE), respectively (Figure 5). The number of morula developed was found to be higher in wheat peptone supplemented group followed by BSA and control groups.

Figure 5: Cleavage rate and morula development of ovine oocytes in media supplemented with various proteins.

The cleavage, morula and blastocyst percent has shown high in CR1aa medium followed by TCM-199+, TCM-199 and TCM- 199- (Figure 6). CR1aa medium with α-tocopherol has shown higher cleavage, morula and blastocyst percent at 200 μM concentration (Table 6).

Table 6: Effect of Vitamins on CR1aa in development of sheep embryos.

Figure 6: Effect of different media on development of sheep embryos.

Sheep play a crucial role within the Indian economy by providing employment to large population of marginal and landless farmers. Embryos Transfer Technology (ETT) helps in quicker multiplication of elite animal to extend genetic gain. For sustainable and eco-friendly animal production system, differing types of biotechnology tools were introduced to increase meat and milk production [13,14]. The modern day technique in Biotechnology leads to develop ‘Dolly’ in July 1996. The in vitro Embryo production (IEP) in Ovine requires the development of maturation, fertilization and culture media particularly to extend cleavage and development rates by the employment of biological research and transgenesis, that intern improved productivity or high commercial value results demand animals of high genetic value [15]. Hence, the knowledge of the Ovine Physiology from the breeds developed in India from few decades.

The IVF needs the conditions that support motility and capacitation of spermatozoa and maintain the viability of the oocytes to be fertilized. The IVC possess a essential importance to develop and produce the embryo and the culture media continued all needs for embryo development. Mammalian embryos in the past are susceptible to damage from reactive oxygen species and they increase the production of oxygen free radicals when cultured in vitro. The sublethal damage may harmfully affect embryonic development, leading to retarded development, perturbation of traditional metabolic pathways [16].

Vitamins C and E docking with metal ions and preventing metalcatalyzed reactions that generate reactive oxygen species (ROS) by IVM of superior grade oocytes in four different media with supplementation of α-tocopherol or L-ascorbic acid [17,18]. IVF of sheep embryos using fresh semen collected and capacitated from slaughtered ram testis in above said media has been experimented in the present research by IVC of sheep embryos in different media with above mentioned supplementation.

In the present study, there is highly significant difference in the maturation rate and were considerably higher in FBS group compared with supplementation of BSA and wheat peptones. A higher maturation rate in FBS group may be due to cumulative effect of hormonal factors [19]. The cleavage rate and morula development is found to be considerably higher within the FBS group followed by BSA and wheat peptone supplemented group). The effect of FBS and estrus sheep serum (ESS) on IVM of sheep oocytes shows that ESS could support the in vitro maturation of the oocytes slightly better [20].

In the present study, an average yield of 4.13 oocytes per ovary was obtained by slicing technique. Different oocyte recovery rate has been reported in the past: 6.4 [21], 9.4 [22] and 6.3 [23].

By slicing the ovary, follicles embedded deeply in the cortex were released and slicing was the efficient method in terms of oocyte yield and quality [24,25]. The oocyte recovery rate obtained in our study was lower when compared with the recovery rate of 9.4 oocytes per ovary [22] and 6.3 [26] and the difference observed in oocyte recovery rate might be due to the differences in breed, season, ovarian status and age.

Oocytes for in vitro maturation are typically selected supported their cumulus investment and homogeneity of cytoplasm. The gap junctions between oocyte and cumulus cells were needed for the transport of growth factors and hormones necessary for normal maturation and developmental competence [27,28]. The gap junctions between the cumulus cells and therefore the oocytes play a necessary role within the transmission of meiosis activating components. The ability of ovine oocytes in beginning of meiosis is interrupted within the absence of initial affiliation between the cumulus cells and therefore the oocyte [23]. Considering the above findings, in the present study, 546 A grade and 648 B grade oocytes with uniform cytoplasm, invested by cumulus cells were selected for further maturation. The oocytes of two grades A and B has been considered for the IVM. Grade C has not been considered during IVM.

In the present study there was a highly significant difference in the maturation rate between groups. The maturation rate was significantly higher in the FBS group and supplementation of BSA and wheat peptones did not significantly improve the maturation rate. The major functions of serum are to provide hormonal factors which stimulate cell growth and proliferation, promotes differentiated functions, transport proteins carrying hormones, minerals trace elements, lipids, attachment and spreading factors and stabilizing and detoxifying factors [19]. The highest maturation rate observed in FBS group may be due to the cumulative effect of the above factors which could have caused better cumulus expansion.

Bovine serum albumin may cause the media semi-defined since commercially available preparations were found to be contaminated with some low molecular weight compounds [29] and further BSA also decreased the developmental capacity of the oocytes [30], which could possibly be the reasons for reduced maturation. Since no controlled studies on supplementation of wheat peptones in maturation media are available and based on the present study it can be inferred that addition of wheat peptones to maturation media may not have beneficial effect on oocyte maturation [31]. However, more controlled and elaborate studies are further needed in this regard.

There was a highly significant difference in the cleavage rate and morula development between groups. The cleavage rate and morula development was found to be significantly higher in the FBS group followed by BSA and wheat peptone supplemented group. The factors leading to improved embryo development in serum containing culture medium are not well understood [32]. It is found that block to embryo development occurred around the time of embryonic genome and supplement of serum prevents this block [33,34].

BSA showed no significant embryo promoting effect on postcleavage embryo development compared to FBS [35,36]. In addition, the embryotrophic effects of BSA might vary between suppliers and even between lots, which could be the possible reasons for the reduced cleavage rate and morula development [29]. Addition of wheat peptones during IVM, IVF and IVC did not improve the cleavage rate and morula yield. Culture media such as CR1 media on developmental competence and cell apoptosis produced better fertilized embryos through in vitro process [37]. Since no controlled studies on wheat peptone supplementation are available no definite conclusion could be drawn.

In the present study, the nuclear maturation rate was significantly higher in the FBS supplemented group followed by BSA and wheat peptone supplemented groups. The higher maturation rate observed in this study in FBS supplemented group could be due to varying concentrations of hormones, trace nutrients and proteins present in serum which were bound to favor nuclear maturation [38]. Since wheat peptones did not result in significant cumulus expansion, its effect on nuclear maturation was also studied which showed no beneficial effect.

Significant difference was not been observed in the cleavage rate and morula development between groups. However, morula development was found to be higher in wheat peptone supplemented group followed by BSA and FBS supplemented group. In embryo culture, wheat peptone supplementation could be a good alternative to other protein supplements. The wheat peptones may supply nutrients, adhesion components or growth factor analogues which enhances the embryo production [39]. Moreover, hydrolyzed plant proteins have anti-apoptotic properties [40] and protective function over metal ions, potential anti-oxidant properties [41] and contains numerous free amino-acids, short oligopeptides, some vitamins and carbohydrates [42] which may cumulatively be responsible for improved embryo production observed in the study.

in vitro production of sheep embryos and effect of the exogenous addition of 200 μM/ml cysteamine and 20 ng/ml epidermal growth factor [43] results have indicated that EGF plays an important role in the IVM and both EGF and cysteamine have a stimulatory effect on further embryonic development in sheep. The maturation percentage recorded in the EGF supplemented medium (84.9%) was significantly higher than in the cysteamine supplemented (69.6%) and control medium (67.2%). The fertilization and cleavage rates recorded were 73.7%, 49.5% in control, 72.3%, 52.7% in cysteamine and 76.5%, 55.5% in EGF supplemented media respectively. The morula formation rate recorded in the EGF supplemented (38.7%) and cysteamine supplemented (36.7%) media was significantly higher, than in the control (22.1%) medium.

The hyperthermia during oocyte maturation and/or fertilization adversely affects oocyte maturation and fertilization rates and retards further embryonic development [44]. The effects of supplementation of synthetic oviduct fluid (SOF) with glucose and Minimal Essential Medium (MEM) vitamins is assessed during the first step of the in vitro culture (SOFC1) of ovine zygotes has been experimented [45]. Vitamins must be present for optimal numbers of embryos to reach the blastocyst stage.

Interestingly the research was also conducted in this study and shown that, wheat peptones when supplemented during IVM, IVF and IVC did not improve the maturation rate and embryo yield for reasons which are unknown but the embryo yield improved when wheat peptone was supplemented only in IVC. However, further studies to determine the optimum concentration of wheat peptones as substitute for animal protein in embryo culture is needed to draw firm conclusions. The overall of this study showed the production of the sheep embryo from the ovaries of the slaughtered ewes and IVM, IVF of the oocytes and then IVC in complex culture media (CR1aa with 200 μM concentration of α -tocopherol).

In the present work, a protocol has been established by IVM, IVF and IVC of sheep oocytes for in vitro production of sheep embryos. Studies on IVM, IVF and IVC using protein supplementation in different concentration are conducted to reveal the beneficial effects of protein supplements in embryo production.

Authors would like to thank management and staff of Chennai Fertility Centre, GITAM University, Dept. of animal Biotechnology, Tamilnadu Veterinary and Animal Sciences University, India for their kind support in bringing out the above literature and providing lab facilities. We also thank CMJ University for providing research support.
