Research Article - (2017) Volume 9, Issue 4
Proteases are widely used in leather processing, silk industry, diary meat processing, and preparation of organic fertilizer as well as for the liberation of silver from recycled X-ray films. Ultraviolet radiation mutagenesis of Bacillus subtilis IBL-04 was carried out for hyper producing strain development. Mutants of Bacillus subtilis were isolated and screened for selection of hyper producing mutant. Production of protease by the selected mutant BS-90 (treated for 90 min) was optimized by varying pH, temperature, and inoculum size and fermentation time simultaneously in Response Surface Method (RSM) under Central Composite Design (CCD). The mathematical response model is considered to be reliable with an R2 value of 0.9842. The adjusted R2 value was 0.9695 suggesting a significant model by determining the close relationship to the actual R2 value. Predicted R2 value shown in this model was 0.9133. The "Pred R-Squared" of 0.9133 is close as to the "Adj R-Squared" of 0.9695 as expected. The ratio of 22.60 attained in this model represents an adequate signal. The calculated C.V was 3.25 which indicate the good level of model precision and reliability. The maximum enzyme activity was 95.89 (IU/mL) at optimum conditions pH 8, Temperature 50°C, Inoculum size 2.5 mL and fermentation time 72 h. These characteristics render its potential use in detergent industries for detergent formulation.
Keywords: Media optimization, Bacillus subtilis, UV mutagenesis, Alkaline detergent proteases, Low-cost media
Proteolytic enzymes or proteases are the most important enzymes in industry, accounting for 60% of the total enzyme sales in the world . They are used in the regulation of metabolism, gene expression, enzyme modification, pathogenicity and diverse processes in the different industries . Microbial proteases play an important role in the production of traditional fermented foods, enzyme industries, dominated by microbial protease products. They also find use in food processing, detergents, therapeutic agents and organic chemical synthesis [3,4]. The demand and supply of proteases can be balanced by developing and exploring new microbial strain to increase their production. Alkaline proteases constitute 60-65% of the global industrial market. These proteases are the single class of enzymes widely used in detergents, pharmaceuticals, leather and the food and agriculture industries. Proteolytic enzymes support the natural healing process in local management of skin ulceration by efficient removal of necrotic material. Proteases catalyze or hydrolyze protein and therefore play a vital role in various industrial applications. Proteolytic enzymes catalyse in tumor invasion and also in infection cycle of pathogenic microorganisms. They are also involve in disease causing organisms which cause of developing therapeutic agents against fatal disease like cancer and AIDS . For maximum yield, selected organisms are grown in fermenters under optimum conditions and can be further used to make products such as cheese, bread, wine and beer .
The production of an enzyme in Bacillus subtilis has a characteristic relationship with regard to the growth phase of the organism. Production of protease is controlled by specific genes that are induced and UV-treated in response to the growth substrates during transition state between exponential growth and the stationary phase. The rate of enzyme production is variable in specific microorganisms. But protease synthesis is correlated with the onset of a high rate of protein turnover [7,8].
Mutation is one of the processes being used to enhance the production of enzymes. Mutations can be induced by the methods of random-mutagenesis or site-directed mutagenesis . The possible alteration in proteins by the process of mutagenesis causes changes in the binding affinity, specificity, catalytic rate and thermo stability of enzymes. By random mutagenesis, new unanticipated mutations at random places are found which have critical importance for the function of protein of interest. However, in some cases random mutation process may lead to the silencing of a gene. While in site-directed mutagenesis, the positions of functional importance are defined in a protein that is a good tool, to understand the protein structure function relationship. The structure function relationships are determined by comparing the amino-acid sequence in native and mutant proteins. UV irradiation and Chemical mutation processes are commonly used. Effective, easy and low cost techniques used for the improvement of microbial strains for developing hyper producing microbial fermentation processes.
UV-B (280 to 320 nm) and UV-C (100 to 280 nm) cause both indirect and direct damage because of the strong absorption at wavelengths below 320 nm by the DNA molecule. The most abundant products formed by irradiation with UV-B are cyclobutane pyrimidine dimers. (CPD) (22). The pyrimidine dimers at specific region of Bacillus subtilis DNA may treat in recovery of protease genes that alters enzyme production .
Bacteria have several repair mechanisms in response to UVRinduced damage. These mechanisms are usually classified into dark repair (DR) and photoreactivation. There are three different dark repair mechanisms described here: (i) nucleotide excision repair, (ii) postreplication recombinational repair, and (iii) error-prone repair. All mechanisms are inducible as part of the SOS regulon and the induction is dependent on DNA damage .
The present study was conducted to improve bacterial strain through mutation and optimized the conditions such as pH, temperature, size of inoculum and fermentation time to enhance enzyme yield to make the process of production cost effective. Structure analysis as well as extensive biochemical and genetic studies of the proteasome and the ubiquitin system led to a basic model of substrate recognition and degradation by enzymes. The proteasome as the proteolytic machine degrading those cellular proteins in vivo that had been tagged with ubiquitin constituted the ignition spark, which led to the explosion of knowledge of a new regulatory principle of eukaryotic cells, now known as selective proteolysis via the ubiquitin–proteasome system (UPS). This system is unique in cellular regulation as in contrast to phosphorylation/dephosphorylation of a protein it allows a complete shutdown of function of a selected protein molecule due to its irreversible proteolysis .
Place of work
The experimental and analytical work was done in industrial biotechnology laboratory (IBL), department of biochemistry, University of Agriculture, Faisalabad. All chemicals used in this study were of analytical grade. These chemicals were purchased from Sigma- USA and Oxide, UK through local agents.
The bacterial strain Bacillus subtilis was obtained from Industrial Biotechnology lab (IBL), Department of Biochemistry, University of Agriculture, Faisalabad. Bacillus subtilis was grown on nutrient agar slants at 37°C for 24 h and then preserved at 4°C for one month .
Luria-Bertania (LB) medium (1.55 g/L) was prepared in 250 mL Erlenmeyer flasks. The pH of the medium was adjusted to 7.5 using NaOH / HCL and autoclaved at (121°C) for 15 min. A loop full Bacillus subtilis cells were transferred into the sterilized medium. The flasks were shaken (200 rpm) for 24 h to get a homogeneous cell suspension .
UV mutagenesis of Bacillus subtilis
To enhance the production of protease enzyme 24 h old culture was taken, centrifuge at 10,000 rpm and the cells were washed twice with phosphate buffer (50 mM, pH 7.0).The pellet was suspended in 50 mM phosphate buffer (pH 7.0) and transfered into sterile Petri plates. One plate was kept in dark which served as control and the rest were exposed to UV radiation for different time intervals varying from 30-120 min with 30 min interval. UV detection lamp 365 nm, Fisher Scientific Ltd., Pandan Crescent, UE Tech Park, Singapore was used. After UV irradiation they were kept in dark for stabilization of thymine-thymine dimers (T-T), followed by inoculation with 0.1 ml of the UV treated bacterial suspensions on skim milk agar plates. These were incubated for 48 h at 37°C for colony formation. Triton X-100 (1- 2%) was the colony restrictor used in the medium. It is a chemical used to restrict the growth of bacterial colonies appearing on the media. The colonies which showed more intense zones on skim milk agar plates were selected as mutants for production of protease .
Liquid state fermentation for protease production
Protease production was carried out by growing the selected mutants in 250 mL Erlenmeyer flasks containing 100 mL of medium. The medium contained the following (g/L) in distilled water: peptone, 1.0; maltose, 4.0; NaNO3;, 0.5; KH2PO4, 0.5;MgSO4.7H2O, 0.02; Na2CO3, 1.0. The medium was sterilized by autoclaving at 121°C for 15 min. The
medium was inoculated with Bacillus subtilis mutants and incubated at 35°C for 24h. After three days, the broth was centrifuge at 10,000 rpm for 20 min at 4°C and the supernatant was used as extracellular enzyme extract .
Protease assay: Protease enzyme activity was measured by the addition of casein in phosphate buffer (pH 7) at 37°C. The oxidation of casein was determined at 660 nm using a UV/Vis spectrophotometer. Enzyme activities were expressed in U/mL .
A=volume of enzyme used
B=Time required for assay (20 min)
C=Volume used in colorimetric determination (1 ml)
Optimization of different factors for hyper production of protease enzyme
After protease production by different mutants, the best protease producer mutant BS-90 (treated for 90 min) was selected. Various fermentation process parameters effecting enzyme production during liquid state fermentation (LSF) were optimized. The parameters optimized were: (1) Incubation temperature (35-55°C); (2) initial pH (6.0-10.0), (3) incubation period (24-120h) and (4) inoculums size (1-4 mL) varied simultaneously adopting Response Surface Methodology (RSM) strategy under Central Composite Design (CCD) using Design Expert software (Version 6.0) (Table 1).
|Independent Variables||Coded levels|
|Inoculum Size (mL)||1||4|
|Fermentation Time (h)||24||120|
Table 1: Ranges of independent experimental variables.
Design expert (version 7.0) depends upon two things which are group of controlled experimental factors and measured responses.
There is a 4 factor design which was used to fit the second order polynomial model. It shows that 30 flask experiments were required for this procedure (Table 2). The optimum values were taken by solving the regression equation. The 30 flasks fermentation experiment was performed as triplicate . The medium with different pH was added in 250 ml Erlenmeyer flasks. The contents of the flask were autoclaved at 121°C. Substrate was inoculated with varying Bacillus subtilis inoculum size in each flask. The contents of the flask were mixed thoroughly and incubated at different temperatures for different fermentation time periods.
|Run||pH||Temperature (°C)||Inoculum Size (mL)||Fermentation Time (h)|
Table 2: RSM optimization design under CCD for the production of protease by BS-90 UV treated mutants of Bacillus subtilis.
In the present study, the UV irradiation mutagenesis was carried out to develop a high protease yielding mutant of Bacillus subtilis IBL- 04. After the selection of hyper-producing mutant strain, the physical parameters (inoculum size, incubation time, pH and temperature) were optimized by RSM (Response Surface Methodology) under CCD (Central Composite Design) to improve the production of protease. Later on, the enzyme was purified and characterized. The results obtained during the research investigations have been described and discussed under the following sub-headings.
UV Induced mutagenesis of Bacillus subtilis IBL-04
Homogeneous cell suspension of Bacillus subtilis were used to treat the bacterial spores in UV irradiation mutagenesis for different time periods (30-120 min) with intervals of 30 min. After UV irradiation, 100 fold serial dilution of mutated spores were plated to give 30 colonies or less per petri plate. UV irradiation was carried out in a semi dark room to increase the protease activity of Bacillus subtilis. The frequency of positive mutation and no of variable colonies increased by increasing the time of irradiation up to a limit. After that no of colonies decreased by increasing time period. The colonies which were showed more clear zones were selected as mutants for hyper production of protease . Bacterial culture exposed to UV radiations for 90 min (UV-90) gave most prominent and relatively bigger size colonies (Figure 1).
Triton X-100 is non-ionic detergent that generally has applications in laboratories. It has lipophobic polyethylene oxide chain and a hydrophobic group consisting of aromatic hydrocarbons chain. It is an efficient colony restrictor which causes to make the good, round, small sized and intense colonies.
Isolation of mutants using skim milk as metabolic inhibitor
The production of protease by Bacillus subtilis IBL-04 mutants was carried out in skim milk (1% w/v) growth medium. Native strain of bacterium was incapable to proliferate in its presence i.e. parent bacterium growth was inhibited. Different UV treated mutants of Bacillus subtilis appearing on agar-plates using 1% skim milk have been show in Figure 2.
A researcher has previously reported the use of skim milk to isolate and select the protease producing mutants . Elevated concentration (1.5%) of skim milk for the isolation of mutants, plated on gelatine containing agar medium have been used and mutants have been screened on the basis of clearance zone shown on the medium. The sequential exposure to UV or Chemical mutagenic agents and the mutant selection with skim milk on the basis of growth restriction has also been reported. After screening it was found that mutated colonies were skim milk resistant.
Protease production by selected mutants
All the UV treated mutants and parent Bacillus subtilis IBL-04 were cultured in LSF for protease enzyme production using casein as substrate. It was observed that all the mutant strains produced higher enzyme activity as compared to parent strain (Table 3). However, the mutant treated for 90 min was the best protease producer (90 IU/mL).
|Sr. No.||Exposure Time(min)||Enzyme Activity(U/mL)|
Table 3: Effect of UV light exposure on protease enzyme production by Bacillus subtilis mutants.
Physical parameters optimization for enhanced production of UV-90 mutant protease by Bacillus subtilis using RSM
Using RSM in liquid substrate fermentation medium (LSF), independent variables were Inoculum size (A), Fermentation Time (B), pH (C) and Temperature (D) and interactive effects of these variables were investigated on the production of protease by Bacillus subtilis-90 mutant using casein as substrate. Four levels of each variable were studies in triplicates. In this study, four different factors were studied in a 30 runs design. The responses (Protease activity) were measured after carrying the experiments. Response values attained are the mean of triplicate trials. The optimal protease activities were observed at inoculum size, 2.50 mL; fermentation time, 72 h; pH, 8 and temperature 50°C (Table 4).
|Run||pH||Temperature (°C)||Inoculum Size (mL)||Fermentation Time (h)||Protease (IU/mL)|
Table 4: Protease activity response by RSM under CCD for optimization of physical parameters.
The optimal operational conditions were found to enhance the mutant protease enzyme production. The single response variable was treated under Central Composite Design (CCD). A pragmatic model having the independent variables effect was developed employing the software to characterize the response surface. The maximum protease activity obtained was 95.89 IU/mL while minimum was 53.78 IU/mL using the same substrate.
For the dependent variable (protease production) or response (Y) a second order polynomial equation was used in terms of linear, cross product and quadratic equations. Statistical calculation was implicit to the coded independent variables according to the Eq. 1 mentioned below:
Here Xi is the non-dimensioned coded value of independent variables, xi is the actual value of that independent variable, xo is the real value of that independent variable xi at the central point, Δ xi is the step change value. The action of every variabl, their interactions and statistical examination to acquire the predicted yields is illustrated by using the quadratic Eq. 2 mentioned below:
In this equation Y is the predicted response, Xi, Xj are levels of independent variables of linear, quadratic coefficients and e is the random error .
ANOVA for the response (protease) surface model
The observed response values variability comparison with the experimental variables and their interaction was calculated by the coefficient of determination (R2). The goodness of model fitting was measured by R2. Its value ranges 0-1 while near to 1 may predict to be a good fitted model . The calculated coefficient of determination for protease production was 0.9842 that could elucidate up to 98.42% response variability. That was comparable to R2 value of 0.9842 . The mathematical response model is considered to be reliable with an R2 value of 0.9842. The adjusted R2 value was 0.9695 suggesting a significant model by determining the close relationship to the actual R2 value. Predicted R2 value shown in this model was 0.9133. The "Pred R-Squared" of 0.9133 is close as to the "Adj R-Squared" of 0.9695 as expected (Table 5).
|Model Terms||Value||Model Terms||Value|
Table 5: ANOVA values for mutant protease hyper production response surface model.
Adequate Precision was used to measure the signal to noise ratio. A ratio larger than 4 is advantageous. Here, the ratio of 22.60 attained in this model represents an adequate signal. It recommends the model was capable to explicate 22.60% of the overall variations. The reliability of the experimental values can be dealt by measuring the coefficient of the variation (C.V). High degree of precision is collaborated with the small value of (C.V). In the present case C.V calculated was 3.25 which indicates the good level of model precision and reliability (Table 6).
|Source||Sum of Squares||DF||Mean Square||F-Value||P-ValueProb>F|
|C: Inoculum Size||52.63521||1||52.63521||8.433002||0.0109|
|D: Fermentation Time||78.3928||1||78.3928||12.55978||0.0029|
|Lack of Fit||72.76973||10||7.276973||1.744753||0.2801||Non- significant|
Table 6: ANOVA for response surface quadratic model.
The results of analysis of variance (ANOVA) are shown in the Table 6. The F test and subsequent P values with the factors were predicted. The lesser the P value, the greater is the importance of corresponding coefficient . Whereas model indicates that the F-value was 66.78. The Quadratic Model has F-value of 66.78 which indicates that the model is significant. Approximately 0.01% chance that the "Model F-Value" could occur due to noise. There is another way which indicates that the model terms are significant if the Values of "Prob>F" are less than 0.0500.
Here some model terms are significant like A, C, D, A2 and AB. If the values are greater than 0.1000 so it shows that the model terms are non-significant.If there are many non-significant model terms so the model reduction may improve your model. The "Lack of Fit F-value" is non-significant which is 1.74. It is extremely near to the pure error. Only 28.01% chance that the "Lack of Fit F-value" could occur due to noise. Non-significant lack of fit is good - we want the model to fit.
Regression coefficient for protease enzyme production from Bacillus subtilis
In case of regression coefficient model, the positive and negative coefficient of any factor indicates that it has significant effect on protease enzyme production. The positive values of linear coefficient indicates that production of protease enzyme increased with initial increase in any factor. While the negative linear coefficient for pH, temperature, inoculum size and fermentation time indicated that at higher levels of these factors protease activity decreased.
The t and p values are usually applied to analyze the significance of each coefficient. Greater t test value and lower the p value depicts greater significance of corresponding coefficient. P value P ≤ 0.01 predicts that model terms are highly significant (Table 7).
Table 7: Estimated regression coefficients for protease production by Bacillus subtilis in LSF.
Interactions between varying variables
The response surface graphs are displayed to elucidate the relations of the different variables and to search the optimum point of all variables to attain a maximum yield. The (3D) plots are usually plotted to explain the interaction between different physicochemical parameters and to find optimal value of each variablefor optimal protease production . The curves were generated by plotting response (Protease production) on the Z-axis opposite to two independent factors whereas maintaining the other independent (factors) variables at their O-level.
Inoculum size vs. fermentation time: The 3D Response Surface Plots showed the highest protease activity 86.7786 IU/mL produced by Bacillus subtilis when pH 6-10 was maximum and temperature ranged from 35-55°C. The interaction between pH and temperature was not significant (Figure 3).
pH vs. temperature: The 3D response surface plots showed the highest protease activity 93.6375 IU/mL produced by Bacillus subtilis when pH 6-10 was maximum and temperature ranged from 35-55°C. The interaction between pH and temperature was significant (Figure 4).
Inoculum size vs. pH: The 3D Response Surface Plots showed the highest protease activity 86.7786 IU/mL produced by Bacillus subtilis when pH 6-10 was maximum and temperature ranged from 35-55°C. The interaction between pH and inoculum size was not significant (Figure 5).
Fermentation time vs. pH: The 3D Response Surface Plots showed the highest protease activity 86.7786 IU/mL produced by Bacillus subtilis when pH 6-10 was maximum and temperature ranged from 35-55°C. The interaction between pH and fermentation time was not significant (Figure 6).
Inoculum size vs. temperature: The 3D Response Surface Plots showed the highest protease activity 93.6375 IU/mL produced by Bacillus subtilis when pH 6-10 was maximum and temperature ranged from 35-55°C. The interaction between inoculum size and temperature was not significant (Figure 7).
Fermentation time vs. temperature: The 3D response surface plots showed the highest protease activity 93.6375 IU/mL produced by Bacillus subtilis when pH 6-10 was maximum and temperature ranged from 35-55°C. The interaction between fermentation time and temperature was not significant (Figure 8).
It was reported that the constant and highest protease enzyme activity was observed at pH between 6-10°C. The optimum pH for alkaline protease was observed at 8°C. The production at pH 7 and 8 are mostly comparable . The maximum enzyme activity was 95.89 (IU/mL) at optimum pH 8. It means pH 8 is more favorable for protease production. It was also observed that if inoculum size was reduced (0.2%) so it may cause less protease enzyme production. Pseudomonas sp. has been reported that 1.5% inoculum showed maximum enzyme production Similarly Bacillus subtilis has 2.5% inoculum size which showed maximum enzyme production. It is relatively comparable. Halobacterium sp. has been reported that maximum protease production was achieved 96 h incubation period. The Bacillus subtilis gave maximum protease production in 72 h incubation time.
The results obtained confirmed that UV-mutagenesis technique is an important tool in Bacillus improvement for increasing production of alkaline protease enzyme. The selected hyper producing Bacillus mutant may have the potential in biotechnological applications.
